MV 650 H - Billy Goat Lawn & Litter Vacuum NOZZLE Parts Diagram

Lawn & Litter Vacuum

NOZZLE Parts Diagram

  • Title

1

Billy Goat 350127

YOKE 1/2 - 20

$21.99

$

Usually ships in 2-11 days

0

2

Billy Goat 350128

PIN YOKE 1/2"

$16.99

$

Usually ships in 2-11 days

0

3

Billy Goat 840243

SCREWCAP BUTTON HEAD 3/8"-16 X 1 1/4" PL

$0.99

$

In Stock, only 2 left!

0

4

Billy Goat 8172009

WASHER 3/8" SAE ZP

$1.49

$

In Stock, Qty 6

0

5

Billy Goat 8161042

NUT LOCK 3/8-16 LT WT THIN ZP

$0.99

$

In Stock, Qty 9

0

6

Billy Goat 8041038

SCREWCAP 5/16 -18 x 3 1/2

$0.99

$

Usually ships in 2-11 days

0

7

Billy Goat 8160002

NYLON INSERT LOCKNUT 5/16-18 UNC

$0.99

$

In Stock, Qty 5

0

8

Billy Goat 8172020

WASHER FLAT FENDER 5/16

$0.99

$

In Stock, Qty 6

0

9

Billy Goat 8161044

NYLON INSERT LOCKNUT 1/2-13 UNC THIN

$0.99

$

In Stock, only 3 left!

0

10

Billy Goat 8171002

WASHER 1/4" FC ZP

$0.99

$

In Stock, Qty 9

0

11

Billy Goat 400424

LABEL WARNING OPEI

$3.99

$

In Stock, only 1 left!

0

12

Billy Goat 8024050

BOLTCARRIAGE 5\16-18X3 1\2

$0.99

$

Usually ships in 2-11 days

0

13

Billy Goat 520156

ROLL PIN 1/4 X 1 LONG

$1.49

$

Usually ships in 2-11 days

0

14

Billy Goat 8172011

WASHER 1/2" SAE ZP

$0.99

$

In Stock, Qty 6

0

15

Billy Goat 840118

NOZZLE MV VAC ASSEMBLY

$474.99

$

Usually ships in 2-11 days

0

16

Billy Goat 840019

CAP 5 IN HOSE VAC

$23.99

$

Usually ships in 2-11 days

0

17

Billy Goat 840024

HANDLE LOWER MV VAC

$71.99

$

Usually ships in 2-11 days

0

18

Billy Goat 840101

WHEEL 14" ASSEMBLY WITH BEARING AND TIRE

$112.99

$

Usually ships in 2-11 days

0

19

Billy Goat 840104

AXLE FRONT WA MV VAC

$151.99

$

Usually ships in 2-11 days

0

20

Billy Goat 840155

HGT ADJ WA W/LABEL MV VAC

$113.99

$

Usually ships in 2-11 days

0

21

Billy Goat 8041004

SCREWCAP 1/4 - 20 x 0.75 HWH

$0.99

$

In Stock, Qty 20+

0

22

Billy Goat 840034

LINK HGT ADJ MV VAC

$20.99

$

Usually ships in 2-11 days

0

23

Billy Goat 840041

BRACKET NOZZLE WEAR GUARD MV VAC

$22.99

$

Usually ships in 2-11 days

0

24

Billy Goat 840029

ROD CONNECT HGT ADJ

$12.99

$

Usually ships in 2-11 days

0

25

Billy Goat 840073

BUSHING 0.5" ID 0.625 OD X X 0.250

$4.49

$

Usually ships in 2-11 days

0

26

Billy Goat 840119

ROD HANDLE CRANK ASSEMBLY

$85.99

$

Usually ships in 2-11 days

0

27

Billy Goat 840057

HANDLE CRANK 0.5 ID X 3.72 LONG

$16.99

$

Usually ships in 2-11 days

0

28

Billy Goat 840078

BUSHING 3/8" ID 1/2" OD X 3/8" LONG

$4.49

$

Usually ships in 2-11 days

0

29

Billy Goat 840158

WASHER LOCK 1/4" TWISTED TOOTH

$4.49

$

Usually ships in 2-11 days

0

30

Billy Goat 840207

NUT PAL 0.5" ID X 0.75 OD

$0.99

$

Usually ships in 2-11 days

0

31

Billy Goat 840135

NOZZLE COVER MV VAC

$297.99

$

Usually ships in 2-11 days

0

32

Billy Goat 840259

LABEL MV BADGING

$12.99

$

Usually ships in 2-11 days

0

33

Billy Goat 840035

SCREW PLASTIC

$0.99

$

In Stock, Qty 10

0

34

Billy Goat 840054

LABEL HGT ADJ MV VAC

$2.99

$

Usually ships in 2-11 days

0

35

Billy Goat 840082

SCREW PLASTITE 1/4"-10 X 3/4 HWH ZP

$1.49

$

In Stock, Qty 6

0

36

Billy Goat 840088

BRACKET NOZZLE COVER REINFORMENT MV

$52.99

$

Usually ships in 2-11 days

0

37

Billy Goat 8024021

BOLT CARRIAGE 1/4-20X0.75

$0.99

$

Usually ships in 2-11 days

0

38

Billy Goat 900455

NUT FLANGE 1/4-20

$1.49

$

Usually ships in 2-11 days

0

208

Billy Goat 840017

MV WHEEL BEARING

$6.49

$

In Stock, only 2 left!

0
