Mower Deck - Cub Cadet 48" Mower Deck, 3-Spindle Hitch, Quick Attachment 38 42 48 Blade SN 218,010 to 400,000 Parts Diagram

48" Mower Deck, 3-Spindle

Hitch, Quick Attachment 38 42 48 Blade SN 218,010 to 400,000 Parts Diagram

  • Title

1

NLA

HANGER ASSY, FRONT

Note: Replaces IH-547434-R2

$

$

Not available

1

Cub Cadet 915-0120

PIN, 3/16 x 1 HV COILED SPRING
(Superseded to 715-0120)

Note: Replaces IH-364436-R1 (Not shown)

$10.99

$

In Stock, only 1 left!

0

2

Cub Cadet 938-3001

BOLT, SHOULDER

Note: Replaces IH-489374-R1

$

$

Not available

2

Cub Cadet 936-0272

WASHER, 17/32 x 1-1/16 x .095
(Superseded to 736-0272)

Note: Replaces IH-120396 (Not shown)

$4.99

$

In Stock, Qty 20+

0

3

Cub Cadet 959-3092

BRACKET ASSY, IDLER ADJ

Note: Replaces IH-489375-R1

$118.99

$

Usually ships in 3-6 days

0

4

NLA

SPACER, IDLER ADJ

Note: Replaces IH-545687-R1

$

$

Not available

4

Cub Cadet 912-0429

NUT, 5/16-18 NYLON INSERT
(Superseded to 712-0429)

Note: Replaces IH-411597-R1 (Not shown)

$4.49

$

In Stock, Qty 20+

0

4

Cub Cadet 936-0275

WASHER, 11/32 x 11/16 x .065 C-Z
(Superseded to 736-0275)

Note: Replaces IH-120393 (Not shown)

$

$

Not available

5

Cub Cadet 759-3041-0498

SUPPORT, IDLER RH

Note: Replaces IH-489602-R1

$

$

Not available

6

Cub Cadet IH-547435-R1

ROD, FRONT MOUNTING

$

$

Not available

6

Cub Cadet 914-3003

PIN, QUICK ATTACHABLE COTTER

Note: Replaces IH-473443-R1 (Not shown)

$4.99

$

In Stock, only 1 left!

0

6

Cub Cadet 914-0111

PIN, 3/32 x 1-1/8 C-Z COTTER
(Superseded to 714-0111)

Note: Replaces IH-137175 (Not shown)

$4.99

$

In Stock, Qty 13

0

6

Cub Cadet 736-3003

WASHER, 17/32 x 3/4 x 16

Note: Replaces IH-21903-R1 (Not shown)

$

$

Not available

7

Cub Cadet 759-3037-0499

SUPPORT ASSY, FRONT PIVOT LINK

Note: Replaces IH-489380-R3

$

$

Not available

7

Cub Cadet 914-0111

PIN, 3/32 x 1-1/8 C-Z COTTER
(Superseded to 714-0111)

Note: Replaces IH-137175 (Not shown)

$4.99

$

In Stock, Qty 13

0

7

Cub Cadet 936-0160

WASHER, 17/32 x 1 x .065 C-Z

Note: Replaces IH-178373-R1 (Not shown)

$4.49

$

In Stock, only 1 left!

0

8

Cub Cadet 959-3095

LINK ASSY, LIFT

Note: Replaces IH-473454-R92

$47.99

$

Usually ships in 3-6 days

0

8

Cub Cadet 914-0111

PIN, 3/32 x 1-1/8 C-Z COTTER
(Superseded to 714-0111)

Note: Replaces IH-137175 (Not shown)

$4.99

$

In Stock, Qty 13

0

8

Cub Cadet 914-3003

PIN, QUICK ATTACHABLE COTTER

Note: Replaces IH-473443-R1 (Not shown)

$4.99

$

In Stock, only 1 left!

0

8

Cub Cadet 936-0272

WASHER, 17/32 x 1-1/16 x .095 C-Z
(Superseded to 736-0272)

Note: Replaces IH-120396 (Not shown)

$4.99

$

In Stock, Qty 20+

0

9

NLA

ARM ASSY, FRAME SIDE

Note: Replaces IH-490467-R1

$

$

Not available

10

Cub Cadet IH-489384-R3

LINK ASSY, MOWER SUPPORT

$60.99

$

Usually ships in 3-6 days

0

10

NLA

NUT, 1/2-13 C-Z HEX.

Note: Replaces IH-120238 (Not shown)

$

$

Not available

11

NLA

BRACKET, MOWER SUPPORT

Note: Replaces IH-489386-R2

$

$

Not available

12

Cub Cadet 747-3013

PIN, MOWER SUPPORT

Note: Replaces IH-489387-R2

$22.99

$

In Stock, only 2 left!

0

12

Cub Cadet 715-3003

PIN, 3/4 HV COILED SPRING

Note: Replaces IH-19928-R1 (Not shown)

$6.99

$

In Stock, Qty 7

0

12

Cub Cadet 936-0272

WASHER, 17/32 x 1-1/16 C-Z
(Superseded to 736-0272)

Note: Replaces IH-120396 (Not shown)

$4.99

$

In Stock, Qty 20+

0

12

NLA

SCREW, 3/8-16 x 1-3/

Note: Replaces IH-180123 (Not shown)

$

$

Not available

12

Cub Cadet 936-0140

WASHER, 17/32 x 13/16 x .065 C-Z
(Superseded to 736-0140)

Note: Replaces IH-120394 (Not shown)

$

$

Not available

12

Cub Cadet 936-0169

WASHER, 3/8 C-Z MED LOCK
(Superseded to 736-0169)

Note: Replaces IH-120382 (Not shown)

$3.99

$

In Stock, Qty 20+

0

12

Cub Cadet 712-0798

NUT, 3/8-16 C-Z HEX.

Note: Replaces IH-120377 (Not shown)

$4.49

$

In Stock, Qty 6

0

13

Cub Cadet 932-3007

SPRING, MOWER SUPPORT PIN

Note: Replaces IH-489388-R1

$

$

Not available

14

Cub Cadet IH-490489-R2

BELT, MULE DRIVE 3/8 X 80

Note: Use with 38" Deck

$44.99

$

In Stock, only 2 left!

0

14

Cub Cadet IH-490489-R2

BELT, MULE DRIVE 3/8 X 80

Note: Use with 42" Deck

$44.99

$

In Stock, only 2 left!

0

14

Cub Cadet IH-489397-R3

BELT, MULE DRIVE 3/8 X 75 1/2 SL

Note: Use with 48" Deck

$46.99

$

In Stock, only 1 left!

0

15

Cub Cadet IH-493164-R91

PULLEY, DRIVE BELT IDLER

$

$

Not available

15

Cub Cadet 710-0347

SCREW, 3/8-16 x 1-3/4 C-Z HEX-HD CAP

Note: Replaces IH-180128 (Not shown)

$5.49

$

In Stock, Qty 20+

0

15

Cub Cadet 910-0427

SCREW, 3/8-16 x 2 HEX-HD CAP
(Superseded to 710-3144)

Note: Replaces IH-180130 (Not shown)

$4.49

$

In Stock, Qty 20+

0

15

Cub Cadet 936-0140

WASHER, 13/32 x 13/16 x .065 C-Z
(Superseded to 736-0140)

Note: Replaces IH-120394 (Not shown)

$

$

Not available

15

Cub Cadet 936-0169

WASHER, 3/8 C-Z MED LOCK
(Superseded to 736-0169)

Note: Replaces IH-120382 (Not shown)

$3.99

$

In Stock, Qty 20+

0

15

Cub Cadet 712-0798

NUT, 3/8-16 C-Z HEX.

Note: Replaces IH-120377 (Not shown)

$4.49

$

In Stock, Qty 6

0

15

Cub Cadet 912-0181

NUT, 3/8-16 CAD NYLON INSERT
(Superseded to 712-0181)

Note: Replaces IH-18253-R1 (Not shown)

$

$

Not available

15

Cub Cadet 712-0342

NUT, 3/8-16 C-Z HEX JAM
(Superseded to 912-3008)

Note: Replaces IH-124829 (Not shown)

$4.99

$

In Stock, Qty 16

0

16

PULLEY, CENTER

Note: REFER TO MAIN FRAME AND KNIFE UNITS

$

$

Not available

16

NLA

SPACER, MOWER

Note: Replaces IH-491961-R1 (Not shown)

$

$

Not available

17

Cub Cadet 759-3040-0498

SUPPORT, IDLER LH

Note: Replaces IH-489601-R1

$

$

Not available

18

Cub Cadet IH-542122-R91

BEARING ASSY, IDLER PULLEY

$

$

Not available
