MaxiSneaker - Toro Maxi Sneaker Series E Trencher (2011) PLOW LIFT/SWING CONTROL VALVE ASSEMBLY P75 PLOW Parts Diagram

Maxi Sneaker Series E Trencher

PLOW LIFT/SWING CONTROL VALVE ASSEMBLY P75 PLOW Parts Diagram

  • Title

Toro AU220409A1

VALVE ASSEMBLY - Control, Plow Lift and Swing

Note: Not illustrated

$5363.99

$

Usually ships in 3-6 days

0

1

Toro AU138306A1

HANDLE - Control, Plow Lift and Swing

$111.99

$

Usually ships in 3-6 days

0

2

Toro AUH438042

HOOK-C

$32.99

$

Usually ships in 3-6 days

0

3

Toro AU427-4077

PIN-CLEVIS

$1.49

$

Usually ships in 3-6 days

0

4

Toro AU432-412

PIN-Cotter 0.062 x 0.75 in ZN
(Superseded to 327-22)

$13.99

$

Usually ships in 3-6 days

0

5

SPOOL - Plow Control Valve, Lift Section

Note: Not serviced separately

$

$

Not available

6

SPOOL - Plow Control Valve, Swing Section

Note: Not serviced separately

$

$

Not available

7

Toro AUH438030

O-RING

$

$

Not available

8

BODY - Control Valve

Note: Not serviced separately

$

$

Not available

Toro AU142999A1

KIT - Load Check

Note: Not illustrated

$

$

Not available

9

PLUG - Load Check

Note: Not serviced separately

$

$

Not available

10

O-RING - Plug

Note: Not serviced separately

$

$

Not available

11

SPRING - Load Check

Note: Not serviced separately

$

$

Not available

12

POPPET - Load Check

Note: Not serviced separately

$

$

Not available

Toro AU138313A1

KIT - Detent Float

Note: Not illustrated

$424.99

$

Usually ships in 3-6 days

0

13

SCREW - Includes Lock Washer, Detent Float

Note: Not serviced separately

$

$

Not available

14

Toro AUN9540

HOUSING - Detent

$

$

Currently unavailable

15

BALL - Detent Cap

Note: Not serviced separately

$

$

Not available

16

Toro AUN9506

SPRING - Detent

$

$

Not available

17

Toro AUD86560

PLUG - Detent

$

$

Currently unavailable

18

SPOOL - Detent

Note: Not serviced separately

$

$

Not available

19

O-RING - Detent Spool

Note: Not serviced separately

$

$

Not available

20

Toro AUD86559

SEAT - Spring, Lift Spool

$

$

Currently unavailable

21

Toro AUD86558

SPRING - Return

$

$

Currently unavailable

22

Toro AUD86557

WASHER - Lift Spool

$

$

Currently unavailable

23

Toro AU132547A1

PLUG - Hex, Power Beyond Port

$

$

Currently unavailable

24

Toro AU237-6012

O-RING - 59/64 ID x 7/64 inch Wide

$1.99

$

Usually ships in 3-6 days

0

Toro AUH674816

KIT - Centering Spring

Note: Not illustrated

$

$

Not available

27

SCREW - Includes Lock Washer

Note: Not serviced separately

$

$

Not available

28

Toro AUN9528

CAP - Bucket Spool End

$

$

Currently unavailable

29

Toro AU62-7108

BOLT - Hex Socket, No. 10 NF x 1/2 inch

$0.99

$

Usually ships in 3-6 days

0

30

Toro AU495-11034

WASHER-FLAT

$0.99

$

Usually ships in 3-6 days

0

31

Toro AUN9529

SEAT - Spring, Spool

$18.99

$

Usually ships in 3-6 days

0

32

Toro AUN9539

SPRING-RETURN

$

$

Currently unavailable

33

WASHER - Spring Seat, Spool

Note: Not serviced separately

$

$

Not available

34

Toro AU141141A1

PLATE - Orifice

$543.99

$

Usually ships in 3-6 days

0

35

Toro AU138303A1

VALVE - Relief

$

$

Currently unavailable
