Maverick HD - Bad Boy Zero-Turn Mower (2024) FRAME SUB ASSEMBLIES (CONT.) 2 Parts Diagram

Zero-Turn Mower

FRAME SUB ASSEMBLIES (CONT.) 2 Parts Diagram

  • Title

1

Bad Boy 051-8067-00

4" 1/4 Fuel Line

$6.99

$

In Stock, only 3 left!

0

2

Bad Boy 051-8067-00

4" 1/4 Fuel Line

$6.99

$

In Stock, only 3 left!

0

3

Bad Boy 067-6059-00

3 Way Fuel Shut-Off Valve 1/4x1/4x1/4

$22.99

$

In Stock, only 3 left!

0

4

Bad Boy 072-8069-00

1/4 Fuel Hose Clamp

$1.49

$

In Stock, only 2 left!

0

5

Bad Boy 051-2025-02

3/16" Vinyl Tubing, 55" Long

$13.99

$

Usually ships in 4-7 days

0

6

Bad Boy 051-8072-00

1/4" Vinyl Tubing

$3.49

$

In Stock, Qty 6

0

7

Bad Boy 067-0020-00

Carbon Canister

$66.99

$

In Stock, only 3 left!

0

8

Bad Boy 072-0002-00

8.6mm Hose Clamp

$2.99

$

Usually ships in 4-7 days

0

9

Bad Boy 072-8070-00

3/16 Vinyl Clamp

$1.99

$

Usually ships in 4-7 days

0

10

Bad Boy 072-8077-00

Roto DW-6.5ST Z3X

$

$

Not available

11

Bad Boy 073-8068-00

fuel line T

$10.99

$

Usually ships in 4-7 days

0

12

Bad Boy 066-8083-00

Fuel Cap

$25.99

$

In Stock, only 3 left!

0

13

Bad Boy 067-4090-00

Fuel Gauge w/Grommet

$49.99

$

In Stock, Qty 19

0

14

Bad Boy 067-6070-00

Rollover Valve W/Grommet

$26.99

$

In Stock, Qty 20+

0

15

Bad Boy 067-9903-00

Fuel Pick-up for 067-2021-00

$

$

Currently unavailable

16

Bad Boy 067-9902-00

Fuel Pick-up for 067-2022-00

$22.99

$

Usually ships in 4-7 days

0
