M48-KW (53AI8CT2050) - Cub Cadet 48" Tank Zero-Turn Mower, 23hp Kawasaki (2009 & Before) Fuel Tank Assembly (2008 & Before) Parts Diagram

48" Tank Zero-Turn Mower, 23hp Kawasaki

Fuel Tank Assembly (2008 & Before) Parts Diagram

  • Title

1

Cub Cadet 951-3124E

Fuel Cap, 3.5, Tethered

$36.99

$

In Stock, only 1 left!

0

2

Cub Cadet 725-0157

Cable Tie

$3.99

$

In Stock, Qty 20+

0

3

Cub Cadet 736-3052

Flat Washer, .406 ID, 1.0 OD, .105

$4.49

$

In Stock, Qty 20+

0

4

Cub Cadet 710-3001

Hex, Cap Screw, 3/8-16, .88

$7.49

$

In Stock, Qty 9

0

5

Cub Cadet 936-0169

Lock Washer, 3/8
(Superseded to 736-0169)

$3.99

$

In Stock, Qty 20+

0

6

Cub Cadet 02003842

Fuel Tank

$187.99

$

In Stock, only 1 left!

0

7

Cub Cadet 936-0463

Flat Washer, 1.4 x .630 x .0515
(Superseded to 736-0463)

$4.49

$

In Stock, Qty 20+

0

8

Cub Cadet 01007425

Fuel Fitting
(Superseded to 751-12478)

$52.99

$

In Stock, only 2 left!

0

9

Cub Cadet 02001908

Fuel Hose Assembly includes:

$88.99

$

In Stock, only 1 left!

0

9

Hose, 1/4" Fuel Line

Note: Purchase locally

$

$

Not available

9

Cub Cadet 00012235

Clamp, Union
(Superseded to 726-04123A)

$3.99

$

In Stock, Qty 6

0

9

Cub Cadet 01003473

Tee Fitting, Fuel

$7.49

$

In Stock, only 1 left!

0

10

Cub Cadet 02002253

Grommet, Fuel Tank

$4.99

$

In Stock, only 2 left!

0

11

Cub Cadet 01000215

Hose Clamp, SAE #4: 1/4-5/8, SS

$

$

Not available
