LT 1046 (13AP11CH710) - Cub Cadet 46" Lawn Tractor (2007 & Before) .Quick Reference Parts Diagram

46" Lawn Tractor

.Quick Reference Parts Diagram

  • Title

Cub Cadet 759-3336

Spark Plug
(Superseded to RC12YC)

$3.49

$

In Stock, Qty 20+

0

Cub Cadet KH-47-883-03-S1

Air Filter & Pre-Cleaner
(Superseded to 4788303S1C)

Note: Command Engine

$27.99

$

In Stock, only 2 left!

0

Cub Cadet KH-32-883-03-S1

Air Filter & Pre-Cleaner
(Superseded to 3288303S1C)

Note: Courage Engine

$27.99

$

In Stock, Qty 13

0

Cub Cadet KH-12-050-01-S

Oil Filter

Note: Command Engine

$13.99

$

In Stock, Qty 20+

0

Cub Cadet KH-52-050-02-S

Oil Filter

Note: Courage Engine

$14.99

$

In Stock, Qty 20+

0

Cub Cadet KH-24-050-10-S

Fuel Filter
(Superseded to 2405013S1C)

Note: Command Engine

$12.99

$

In Stock, Qty 20+

0

Cub Cadet KH-25-050-22-S1

Fuel Filter

Note: Courage Engine

$9.99

$

Usually ships in 2-5 days

0

Cub Cadet KH-24-584-45-S

Ignition Module
(Superseded to KH-24-584-201-S)

$110.99

$

Usually ships in 3-6 days

0

Cub Cadet KH-41-403-09

Voltage Regulator
(Superseded to KH-25-403-37-S)

$

$

Not available

Cub Cadet KH-24-393-16

Fuel Pump

$

$

Not available

Cub Cadet KH-24-757-46-S

Carb Kit

$137.99

$

In Stock, only 1 left!

0

Cub Cadet KH-24-757-45-S

Carburetor Solenoid

$246.99

$

In Stock, only 1 left!

0

Cub Cadet 754-0461

Drive Belt
(Superseded to 954-0461)

Note: (Trans)

$59.99

$

In Stock, Qty 20+

0

Cub Cadet 754-04153

P.T.O. & Deck Belt
(Superseded to 954-04153A)

Note: Refer to Mower Deck 46 inch 618-0660 spindle SN 1A267H & after

$84.99

$

Usually ships in 3-6 days

0

Cub Cadet 754-04118

P.T.O. & Deck Belt
(Superseded to 954-04118)

Note: Refer to Mower Deck 46 inch 618-0660 spindle SN 1A257H & before

$66.99

$

Usually ships in 3-6 days

0

Cub Cadet 754-04033

P.T.O. & Deck Belt
(Superseded to 954-04033A)

Note: Deck w/ Spindle 618-04123B

$50.99

$

In Stock, only 3 left!

0

Cub Cadet 742-04125

Blades (Outside)
(Superseded to 942-0611A)

Note: Deck w/ Spindle 618-0660

$29.99

$

In Stock, Qty 20+

0

Cub Cadet 742-04015

Blades (Outside)
(Superseded to 759-04019)

Note: Deck w/ Spindle 618-04123B

$38.99

$

In Stock, only 2 left!

0

Cub Cadet 742-04124

Blade (Center)
(Superseded to 942-0612A)

Note: Deck w/ Spindle 618-0660

$29.99

$

In Stock, Qty 15

0

Cub Cadet 742-04016

Blade (Center)
(Superseded to 759-04020)

Note: Deck w/ Spindle 618-04123B

$32.99

$

In Stock, only 2 left!

0

Cub Cadet 712-0417A

Blade Nut

Note: Deck w/ Spindle 618-0660

$6.99

$

In Stock, Qty 20+

0

Cub Cadet 712-3078

Blade Nut

Note: Deck w/ Spindle 618-04123B

$9.99

$

In Stock, Qty 20+

0

Cub Cadet 618-0660

Spindle Assy. w/Pulley
(Superseded to 918-0625B)

Note: Deck w/ 3 Pulleys & 2 Idler Pulleys

$140.99

$

In Stock, only 4 left!

0

Cub Cadet 618-04123B

Spindle Assy. w/Pulley
(Superseded to 918-04123B)

Note: Deck w/ 3 Pulleys & 1 Idler Pulley

$

$

Not available

Cub Cadet 734-04155

Deck Wheels (Front)

$20.99

$

In Stock, Qty 20+

0

Cub Cadet 734-04039

Deck Wheels (Front)
(Superseded to 753-04856A)

Note: Deck w/ Spindle 618-04123B

$20.99

$

In Stock, Qty 20+

0

Cub Cadet 734-0973

Deck Wheels (Back)

$12.99

$

In Stock, Qty 20+

0

Cub Cadet 725-04227B

Ignition Switch Module
(Superseded to 925-06119C)

$116.99

$

In Stock, Qty 20+

0

Cub Cadet 725-04258

P.T.O. Switch
(Superseded to 925-04258A)

$56.99

$

In Stock, only 4 left!

0

Cub Cadet 725-1648

P.T.O. Relay
(Superseded to 925-1648A)

$47.99

$

In Stock, Qty 7

0

Cub Cadet 721-0342

Gasket
(Superseded to 921-0342)

Note: use with 725-1648

$7.99

$

In Stock, only 3 left!

0

Cub Cadet 717-04174A

P.T.O. Clutch
(Superseded to 917-04174A)

$679.99

$

Usually ships in 3-6 days

0

Cub Cadet KH-25-357-05-S

Engine Oil
(Superseded to KH-25-357-63-S)

$

$

Not available

Cub Cadet 737-3121

Transmission Fluid

$77.99

$

In Stock, only 2 left!

0

Cub Cadet 490-900-0041

Leveling Guage

Note: Accessory

$

$

Not available
