LR 12 (954000762-A) - Husqvarna Lawn Tractor (1994-01) Dash Parts Diagram

Lawn Tractor

Dash Parts Diagram

  • Title
1

Husqvarna 532132735

Cap, Fuel Tank
(Superseded to 532142187)

$

$

Not available

2

Husqvarna 532138392

Assembly, Dash & Fuel Tank

$

$

Not available

3

Husqvarna 532123487

Clamp, Hose

$7.49

$

In Stock, only 1 left!

0

4

Husqvarna 532008544

Line, Fuel
(Superseded to 532000295)

$

$

Not available

5

Husqvarna 532008548

Line, Fuel

$7.99

$

In Stock, only 1 left!

0

6

Husqvarna 873510400

Nut, Hex, Keps 1/4-20
(Superseded to 873680400)

$4.99

$

In Stock, Qty 16

0

7

Husqvarna 532124996

Clip, Fuel Line
(Superseded to 532002751)

$

$

Not available

8

Husqvarna 819091216

Washer 9/32 x 3/4 x 16 Gauge

$

$

Not available

17

Husqvarna 872110404

Bolt, Carriage 1/4-20 x 1/2 Grade 5

$9.49

$

Usually ships in 3-10 days

0

18

Husqvarna 532131886

Support Assembly, Dash

$

$

Not available

19

Husqvarna 532134744

Brace, Cross

$

$

Not available

20

Husqvarna 817060408

Screw, Self-Tapping 1/4-20 x 1/2

$5.99

$

In Stock, only 2 left!

0

21

Husqvarna 532134014

Plug, Dome, Black

$

$

Not available
