Lo-Boy - International Harvester Cub Lo-Boy Tractor (SN: 00501 - 10000) Combination Rear Light & Tail Light Parts Diagram

Cub Lo-Boy Tractor

Combination Rear Light & Tail Light Parts Diagram

  • Title

1

Cub Cadet IH-361985-R93

LIGHT ASSY. COMBINATION REAR AND TAIL 6 VOLT

Note: (ORDER LIGHT ASSY. 373305-R91)

$

$

Currently unavailable

2

Cub Cadet IH-355423-R91

KNOB, SWITCH W/SCREW - METAL

Note: (USED WITH SWITCH BODY WITH 5/16 IN. SHAFT)

$

$

Currently unavailable

3

Cub Cadet IH-359773-R91

KNOB, SWITCH-PLASTIC

Note: (USED ONLY WITH SWITCH BODY WITH 15/32 IN SHAFT)

$

$

Currently unavailable

4

Cub Cadet IH-355425-R1

NUT, SWITCH RETAINING

$

$

Currently unavailable

5

Cub Cadet IH-375653-R92

SWITCH ASSY. LIGHT LESS WIRING

Note: (REPLACES 359682-R91)

$

$

Currently unavailable

6

BODY, REAR LIGHT

Note: (NOT SERVICED SEPARATELY, ORDER LIGHT ASSY, 373305-R91)

$

$

Not available

7

Cub Cadet IH-356590-R91

REFLECTOR, REAR LIGHT

$

$

Currently unavailable

8

Cub Cadet IH-142309

LAMP, NO 1133 -6 VOLT-

$

$

Not available

9

Cub Cadet IH-53527D

GASKET REAR LIGHT

$

$

Not available

10

Cub Cadet IH-350478-R1

LENS REAR LIGHT

$

$

Currently unavailable

11

Cub Cadet IH-53525DA

MOULDING, REAR LIGHT

$

$

Currently unavailable

12

Cub Cadet IH-53526D

SCREW REAR LIGHT DOOR

$

$

Currently unavailable

13

Cub Cadet IH-356592-R91

JEWEL ASSY.

$

$

Currently unavailable

14

Cub Cadet IH-115273

LAMP, NO. 51 - 6 VOLT

$

$

Currently unavailable

15

Cub Cadet IH-68417D

PACKAGE, TERMINAL PLATE ASSY.

$

$

Currently unavailable
