LE 309 - Husqvarna Walk-Behind Edger (1996-01) Curb Hopper Assembly Parts Diagram

Walk-Behind Edger

Curb Hopper Assembly Parts Diagram

  • Title
170

Husqvarna 601000649

BRKT, CURB HOP MNT
(Superseded to 601002477)

$

$

Not available

171

Husqvarna 601000028

SCREW, 5/16-18X .75

$

$

Not available

172

Husqvarna 601000059

NUT, 5/16-18 REGHEXCTRLK

$6.99

$

In Stock, only 2 left!

0

180

Husqvarna 601000007

BOLT, 5/16-18X2.00

$

$

Not available

181

$

$

Not available

182

Husqvarna 601000586

SPACER, SLEV .356X.63X1.01

$

$

Not available

183

Husqvarna 601000019

WASHER, FLAT .344X.69X.065

$3.49

$

In Stock, only 1 left!

0

184

Husqvarna 601000684

KNOB, T W/516/18 NUT
(Superseded to 601400069)

$14.99

$

In Stock, only 1 left!

0

185

Husqvarna 601000012

NUT, 5/16-18 REGHEX

$

$

Not available

186

Husqvarna 601000576

ROD, WHEEL SUPPORT

$

$

Not available
