Lawn Mower - BCS America 38" Rotary Lawn Mower Attachment (1994 & Before) 38" Deck Catcher (SN: 118459 - 131395) Parts Diagram

38" Rotary Lawn Mower Attachment

38" Deck Catcher (SN: 118459 - 131395) Parts Diagram

  • Title

1

BCS America 300.00001

LUBRICATOR M10

$

$

Not available

2

BCS America 311.11088

SCREW TE M4 X 40

$1.49

$

Usually ships in 5-8 days

0

3

BCS America 311.11089

SCREW M5 X 10

$0.99

$

Usually ships in 5-8 days

0

4

BCS America 311.11091

SCREW TE M6 X 14

$1.49

$

In Stock, only 4 left!

0

5

BCS America 31112050

SCREW M5 X 16

$0.99

$

Usually ships in 5-8 days

0

6

BCS America 311.12155

SCREW TE M8 X 45 UNI 5739-8G

$1.49

$

Usually ships in 5-8 days

0

7

BCS America 31121560

SCREW M6 X 20

$1.49

$

Usually ships in 5-8 days

0

8

BCS America 311.21801

SCREW TTQ M8 X 20 UNI 5731

$1.99

$

Usually ships in 5-8 days

0

9

BCS America 31211050

NUT M8

$0.99

$

Usually ships in 5-8 days

0

10

BCS America 31241040

NUT

$0.99

$

Usually ships in 5-8 days

0

11

BCS America 31241050

NUT, SELF LOCKING M5 STAND.

$0.99

$

Usually ships in 5-8 days

0

12

BCS America 31241060

NUT, SELF LOCKING M6

$0.99

$

In Stock, only 4 left!

0

13

BCS America 31241080

NUT, SELF LOCKING M8

$0.99

$

In Stock, Qty 11

0

14

BCS America 314.11053

WASHER, FLAT 5.3

$0.99

$

Usually ships in 5-8 days

0

15

BCS America 314.11064

WASHER, FLAT 6.4

$0.99

$

In Stock, Qty 10

0

16

BCS America 31412210

WASHER, FLAT 21 UNI 1736

$1.99

$

Usually ships in 5-8 days

0

17

BCS America 314.21062

SUPER WASHER

$0.99

$

Usually ships in 5-8 days

0

18

BCS America 314.23084

WASHER, LOCK 8.4

$0.99

$

In Stock, Qty 10

0

19

BCS America 31510100

SCREW 6.3 X 19

$1.49

$

In Stock, only 2 left!

0

20

BCS America 341.10028

COTTER PIN A 3 X 15 UNI 1336 AC.

$0.99

$

In Stock, only 2 left!

0

21

BCS America 341.10042

PIN, COTTER A 4 X 30 UNI 1336

$0.99

$

Usually ships in 5-8 days

0

22

BCS America 551.42758

HANDLE RUBBER

$16.99

$

Usually ships in 5-8 days

0

23

BCS America 552.43904

BUSHING

$16.99

$

Usually ships in 5-8 days

0

24

BCS America 552.47348

L.H. CONVEYOR

$156.99

$

Usually ships in 5-8 days

0

25

BCS America 561.47199

FLAP DOG

$7.49

$

Usually ships in 5-8 days

0

26

BCS America 561.47354

BRACKET

$10.99

$

Usually ships in 5-8 days

0

27

BCS America 561.51364

BAFFLE PIN

$28.99

$

Usually ships in 5-8 days

0

28

BCS America 561.51366

U-BOLT

$25.99

$

Usually ships in 5-8 days

0

29

BCS America 580.02052

PIN

$1.99

$

In Stock, only 3 left!

0

30

BCS America 580.47353

SPRING

$55.99

$

Usually ships in 5-8 days

0

31

BCS America 580.47391

GRASS CATCHER BAG

$271.99

$

Usually ships in 5-8 days

0

32

BCS America 580.50512

SAFETY PIN

$15.99

$

Usually ships in 5-8 days

0

33

BCS America 580.51361

TRANSFER

$22.99

$

Usually ships in 5-8 days

0

34

BCS America 580.51365

DEFLECTOR SPRING

$18.99

$

Usually ships in 5-8 days

0

35

BCS America 581.47379

WHEEL 3.00 - 4

$

$

Currently unavailable

36

BCS America 590.47175

LONG SUPPORT

$216.99

$

Usually ships in 5-8 days

0

37

BCS America 590.47177

TIEROD

$138.99

$

Usually ships in 5-8 days

0

38

BCS America 59047180

WIDE FORK

$201.99

$

Usually ships in 5-8 days

0

39

BCS America 590.47183

LONG PIN

$67.99

$

In Stock, only 2 left!

0

40

BCS America 590.47189

BAG FRAME

$797.99

$

Usually ships in 5-8 days

0

41

BCS America 590.47301

LAWN MOWER CRANKCASE

$

$

Currently unavailable

42

BCS America 590.4735

L.H. FLAP

$

$

Currently unavailable

43

BCS America 590.47386

REAR PROTECTION

$121.99

$

Usually ships in 5-8 days

0

44

BCS America 590.47404

BAG FRAME BOTTOM

$1060.99

$

Usually ships in 5-8 days

0

45

BCS America 590.51336

DEFLECTOR

$

$

Currently unavailable

46

BCS America 590.51358

CONVEYOR

$182.99

$

Usually ships in 5-8 days

0
