K321-6006 - Kohler K-Series Engine, Made for Gravely, 14hp, 10.4kW Baffles & Shroud 2-10-82 (TP-691-B) Rev 10/18/2006 Parts Diagram

K-Series Engine, Made for Gravely, 14hp, 10.4kW

Baffles & Shroud 2-10-82 (TP-691-B) Rev 10/18/2006 Parts Diagram

  • Title

2

Kohler 237520-S

BAFFLE, HEAD - (#DSC)

Note: Center spark plug location. Use 235049-S before Serial No. 3185000. Use 237677-S on engine spec suffix "C" & later

$

$

Not available

4

Kohler 236676-S

BAFFLE, CYLINDER

Note: Use 235054-S before Serial No. 3185000

$24.99

$

Usually ships in 2-5 days

0

7

Kohler 236985-S

KIT, BLOWER HOUSING

$356.99

$

Usually ships in 2-5 days

0

9

Kohler 235652-S

BAFFLE, SIDE AIR

$20.99

$

Usually ships in 2-5 days

0

12

Kohler 236847-S

DEFLECTOR

$68.99

$

Usually ships in 2-5 days

0

X-22-22-S

Kohler X-22-22-S

WASHER, EXT TOOTH LOCK #10

Note: NOT ILLUSTRATED

$3.99

$

Usually ships in 2-5 days

0

X-25-53-S

Kohler X-25-53-S

WASHER, FLAT 1/4" (O.D. 5/8")

Note: NOT ILLUSTRATED

$3.49

$

Usually ships in 2-5 days

0

X-97-3-S

Kohler X-97-3-S

SCREW, IND SLT HD 10-24X3/8" USE 25 086 79-S
(Superseded to 25 086 79-S)

Note: NOT ILLUSTRATED

$2.49

$

Usually ships in 2-5 days

0

X-132-2-S

Kohler X-132-2-S

SCREW - DISCONTINUED

Note: NOT ILLUSTRATED

$2.99

$

In Stock, Qty 6

0

X-132-6-S

Kohler X-132-6-S

SCREW, SEMS 1/4-20-1/2"

Note: NOT ILLUSTRATED

$3.49

$

Usually ships in 2-5 days

0

236715-S

Kohler 236715-S

DECAL, 14 HP

Note: NOT ILLUSTRATED

$22.99

$

Usually ships in 2-5 days

0
