K 400 (UT-15180) - Homelite String Trimmer Muffler - Air Cleaner Parts Diagram

String Trimmer

Muffler - Air Cleaner Parts Diagram

  • Title
A

Homelite UP04634

MUFFLER ASSY.
(Superseded to PA01073)

$35.99

$

Usually ships in 3-7 days

0

1

Homelite UP04258

SCREW, Taptite- (8-32 X 3/8")
(Superseded to PS03999)

Note: Torque Specs 25-35 In/Lbs; 2.8-4.0 Nm

$

$

Not available

2

Homelite UP04629

SCREEN-Spark
(Superseded to 06502)

$

$

Not available

3

Homelite UP04710

GASKET-Muffler
(Superseded to 09343)

$

$

Not available

4

Homelite UP04258

SCREW, Truss Hd. - (10-24 X 2.188)
(Superseded to PS03999)

Note: Torque Specs 50-60 In/Lbs; 5.6-6.8 Nm

$

$

Not available

D

Homelite UP00022

AIR FILTER KIT (Clutch)
(Superseded to 983930001)

$

$

Not available

5

Homelite D98760B

FILTER-AIR
(Superseded to 98760)

$

$

Not available

6

Homelite UP03885

NUT-Hex (10-24)
(Superseded to 81208)

Note: Torque Specs 30-40 In/Lbs; 3.4-4.5 Nm

$

$

Not available
