HydroCut (5900604) - Ferris HydroCut Series 32" Walk-Behind Mower, 13hp Kawasaki Electrical Group - Electric Start - S/N: 2013136020 & Below Parts Diagram

HydroCut Series 32" Walk-Behind Mower, 13hp Kawasaki

Electrical Group - Electric Start - S/N: 2013136020 & Below Parts Diagram

  • Title

1

Ferris 5021542

POSITIVE (+) BATTERY CABLE, 30"
(Superseded to 5021542SM)

Note: (See Motion Control, Parking Brake & Operator Presence Group - Electric Start)

$29.99

$

Usually ships in 2-12 days

0

2

Ferris 5022180

SWITCH, BLADE ENGAGEMENT
(Superseded to 1722887SM)

$33.99

$

In Stock, Qty 20+

0

3

Ferris 5020927

SWITCH, IGNITION, 6 POST
(Superseded to 5020927FS)

Note: (Includes Ref No. 4 - 6)

$33.99

$

In Stock, Qty 12

0

4

Ferris 5022789

KEY, IGNITION MOLDED SET

$

$

Currently unavailable

5

Ferris 5022790

COVER, PLASTIC, SNAP ON
(Superseded to 1704346SM)

$4.49

$

In Stock, only 1 left!

0

6

Ferris 5022791

PLASTIC NUT
(Superseded to 5022791SM)

$3.49

$

In Stock, only 1 left!

0

7

Ferris 5061470

WIRE HARNESS, MAIN, HYDROCUT

$

$

Currently unavailable

8

Ferris 5022438

SWITCH, Plunger, NO/NO
(Superseded to 5022438SM)

$20.99

$

In Stock, Qty 7

0

9

Ferris 5021769

SWITCH, PLUNGER, N.C.
(Superseded to 5021769SM)

$14.99

$

In Stock, only 2 left!

0

10

Ferris 5021405

POSITIVE (+) BATTERY CABLE, 22"
(Superseded to 5021405SM)

$18.99

$

Usually ships in 2-12 days

0

11

Ferris 5025126

NUT, 1/4-20 HEX SERR. FLANGE
(Superseded to 5025126FS)

$4.49

$

Usually ships in 2-12 days

0

12

Ferris 5025010X6

BOLT, 1/4-20 x 3/4
(Superseded to 5025010X6SM)

$3.99

$

In Stock, Qty 20+

0

13

Ferris 5021406

BATTERY CABLE, NEG, 22, 1/4-5/16
(Superseded to 5021406SM)

$16.99

$

Usually ships in 2-12 days

0

14

BATTERY, Lawn & Garden, 12V (BCIU1, 340 CCA)

$

$

Not available

15

Ferris 5023216

NUT, Hex Jam, 5/16-24
(Superseded to 5023216SM)

$2.99

$

Usually ships in 2-12 days

0

16

Ferris 5023217

WASHER, Light Lock, 5/16
(Superseded to 5023217SM)

$3.49

$

Usually ships in 2-12 days

0

17

Ferris 1724815

SOLENOID
(Superseded to 1724815FS)

$29.99

$

Usually ships in 2-12 days

0
