HUV 4210 G - Husqvarna 4x2 Utility Vehicle (2005-06) Brake Pedal And Cable Assembly - Vehicle With Two-Wheel Brakes Parts Diagram

4x2 Utility Vehicle

Brake Pedal And Cable Assembly - Vehicle With Two-Wheel Brakes Parts Diagram

  • Title

1

Husqvarna 603000113

Bumper, Brake Pedal Rubber

$

$

Not available

2

Husqvarna 603000115

Screw, 5/16-18 X 2.50 Hex Cap

$

$

Not available

3

Husqvarna 603002030

Hill Brake Spacer

$

$

Not available

4

Husqvarna 603002032

Spring, Hill Brake Torsion
(Superseded to 603003042)

$

$

Not available

5

Husqvarna 603000121

Package, Brake Mounting Block

$

$

Not available

6

Husqvarna 603002035

Kit, Hill Brake Pedal
(Superseded to 603003043)

Note: (Includes items 7 through 10)

$

$

Not available

7

Husqvarna 603002061

Pad, Hill Brake
(Superseded to 603003065)

$

$

Not available

8

Husqvarna 603002062

Pushnut, 3/8
(Superseded to 603003066)

$

$

Not available

9

Husqvarna 603002340

Bushing, Nylon
(Superseded to 603003302)

$

$

Not available

10

Husqvarna 603000081

Screw, #10-16 Type Ab Sht Mtl

$

$

Not available

11

Husqvarna 603002038

Kit, Hill Brake Latch
(Superseded to 603003046)

Note: (includes items 12 through 18)

$

$

Not available

12

Husqvarna 603002027

Sleeve, Hill Brake Rod
(Superseded to 603003037)

$

$

Not available

13

Husqvarna 603002029

Pushnut, 3/8
(Superseded to 603003039)

$

$

Not available

14

Husqvarna 603002031

Ball Joint, 1/4-28
(Superseded to 603003041)

$

$

Not available

15

Husqvarna N/A

Rod, Hlll Brake

$

$

Not available

16

Husqvarna 603002159

Pin, Cotter, 7/64 x 1/2 Stainless-Steel
(Superseded to 603003155)

$

$

Not available

17

Husqvarna N/A

Pawl, Hill Brake

$

$

Not available

18

Husqvarna N/A

Ratchet Assembly

$

$

Not available

19

Husqvarna 603002206

Brake Pedal Kit
(Superseded to 603003200)

Note: (includes items 20 and 21)

$

$

Not available

20

Husqvarna 603002060

Pad, Brake Pedal
(Superseded to 603003064)

$

$

Not available

21

Husqvarna 603000081

Screw, #10-16 Type Ab Sht Mtl

$

$

Not available

22

Husqvarna 603000882

Pin, Bow Tie Locking

$

$

Not available

23

Husqvarna 603000883

Pin, 3/8 X 1-5/16 Clevis
(Superseded to 603002601)

$

$

Not available

24

Husqvarna 603000062

Nut, 1/4-20 Hex

$

$

Not available

25

Husqvarna 603000065

Washer, 5/16 Type A Flat

$

$

Not available
