HP 22 T - Weed Eater String Trimmer Cutting Head Assembly Parts Diagram

String Trimmer

Cutting Head Assembly Parts Diagram

  • Title
1

Poulan 530093900

"D" Handle
(Superseded to 530069496)

$

$

Not available

$1.99

$

Usually ships in 3-10 days

0

3

Poulan 530095133

Drive Shaft Housing Models HP22 & HP30T

$

$

Not available

3

Poulan 530095134

Drive Shaft Housing Models HP22T

$

$

Not available

$2.49

$

In Stock, only 1 left!

0

5

$3.99

$

Usually ships in 3-10 days

0

6

Poulan 530029159

Shaft Warning Decal

$

$

Not available

7

Poulan 530094679

Drive Shaft

$

$

Not available

8

Poulan 530031111

Hex Wrench (5/32)
(Superseded to 530031159)

$4.99

$

In Stock, only 1 left!

0

9

Poulan 530069299

Shield Kit Ass'y.

Note: (Incl. #10,11,12 & 14)

$

$

Not available

10

$3.99

$

Usually ships in 3-10 days

0

11

Poulan 530094570

Line Limiter

$5.99

$

In Stock, only 2 left!

0

12

Poulan 530015653

Locknut
(Superseded to 534235901)

$3.99

$

Usually ships in 3-10 days

0

13

Poulan 530029373

Shield Bracket

$0.99

$

Usually ships in 3-10 days

0

14

Poulan 530092243

Screw
(Superseded to 530016107)

$3.99

$

In Stock, Qty 11

0

15

Poulan 530094543

Dust Cup

$

$

Not available

16

Poulan 530030102

Shaft Lubrication
(Superseded to 952708514)

$

$

Not available

17

Poulan 952701618

Cutting Head Ass'y.
(Superseded to 952715542)

$

$

Not available

18

Poulan 530094875

Hub Ass'y.

$

$

Not available

19

$3.99

$

In Stock, Qty 20+

0

20

Poulan 530094827

Release Button

$

$

Not available

21

Poulan 952701619

Spool w/Line

$

$

Not available

22

$

$

Not available

Poulan 530068745

Operator's Manual Model HP22

Note: Not Shown

$3.99

$

Usually ships in 3-10 days

0

Poulan 530068609

Operator's Manual Model HP30T

Note: Not Shown

$3.99

$

Usually ships in 3-10 days

0

Poulan 530068608

Operator's Manual Model HP22T

Note: Not Shown

$4.99

$

Usually ships in 3-10 days

0

Poulan 530014750

Carton Contents Bag

Note: Not Shown

$

$

Not available

Poulan 530061597

Carton Model HP22

Note: Not Shown

$

$

Not available

Poulan 530061598

Carton Model HP22T

Note: Not Shown

$

$

Not available

Poulan 530061599

Carton Model HP30T

Note: Not Shown

$

$

Not available
