Horse-OPC - Troy-Bilt Rear-Tine Tiller, 7 & 8hp (SN: 00923347 - 00940749) HANDLE BAR ASSEMBLY Parts Diagram

Rear-Tine Tiller, 7 & 8hp

HANDLE BAR ASSEMBLY Parts Diagram

  • Title
1

Troy-Bilt GW-9548

BOLT 1/2-13X3.5 FH GR5

$14.99

$

Usually ships in 3-6 days

0

2

Troy-Bilt GW-9119

KNOB-CONTROL

$11.99

$

In Stock, Qty 8

0

3

Troy-Bilt GW-9120

RING-TOLERANCE .5325 ID

$6.99

$

In Stock, only 1 left!

0

4

Troy-Bilt GW-1881

STUD-H/BAR W/NUT & RING

$62.99

$

Usually ships in 3-6 days

0

5

Troy-Bilt GW-9803

NUT-HEX JAM 1/2-13
(Superseded to 912-0206)

$4.49

$

In Stock, Qty 20+

0

6

Troy-Bilt GW-1021-1

CLAMP-LH HORSE 1021-1
(Superseded to 1900854010)

$36.99

$

Usually ships in 3-6 days

0

7

Troy-Bilt GW-2542-1

RATCHET-H/BAR RED 2542-1
(Superseded to 1900856010)

$42.99

$

Usually ships in 3-6 days

0

8

Troy-Bilt GW-2542-2

RATCHET-RH RED HORSE 2542-2
(Superseded to 1900857010)

$49.99

$

Usually ships in 3-6 days

0

9

Troy-Bilt GW-1021-2

CLAMP-RH HORSE 1021-2
(Superseded to 1900855010)

$38.99

$

Usually ships in 3-6 days

0

10

Troy-Bilt GW-2534A

BASE-H/BAR RED 2534A
(Superseded to 1900858010)

$125.99

$

In Stock, only 1 left!

0

11

MTD GW-2704

ASSM-HANDLEBAR W/GRIPS

$

$

Not available

12

Troy-Bilt GW-9125

GRIP-H/BAR SMOOTH
(Superseded to 720-04083)

$14.99

$

In Stock, only 2 left!

0

13

MTD GW-2715

DECAL-CONTROL PANEL HORSE

$

$

Not available

14

Troy-Bilt GW-9547

BOLT-CH 1/4-20X2.00 ZP

$

$

Not available

15

Troy-Bilt GW-9844

NUT-HF/LK 1/4-20 ZP
(Superseded to 1186389)

$3.49

$

Usually ships in 3-6 days

0

16

Troy-Bilt GW-9444

CABLE-THROTTLE 7 I/C B&S
(Superseded to GW-9444P)

$85.99

$

Usually ships in 3-6 days

0

?16A

MTD GW-9650

CABLE-THROTTLE 8HP OPC

$

$

Not available

17

MTD GW-2722

DECAL-FWD INTERLOCK

$

$

Not available

18

Troy-Bilt GW-9202

TIE-RED
(Superseded to 725-0157)

$3.99

$

In Stock, Qty 20+

0

19

Troy-Bilt GW-9219

RETAINER-HARNESS H/B OPC

$10.99

$

Usually ships in 3-6 days

0

20

Troy-Bilt GW-2551

HARNESS-WIRE OPC HORSE

$

$

Not available

21

Troy-Bilt GW-9250

SWITCH-H/B OPC
(Superseded to 725-05005)

$30.99

$

Usually ships in 3-6 days

0

22

MTD GW-9385

PIN-LK .11X.58 HORSE OPC

$

$

Not available

23

Troy-Bilt GW-2543

HOUSING-SWITCH OPC
(Superseded to 625-04097)

$72.99

$

In Stock, only 1 left!

0

24

MTD GW-9533

SCR-HW M10-24X.5 STH ZP

$

$

Not available

24A

MTD GW-9533

SCR-HW M10-24X.5 STH ZP

$

$

Not available

25

Troy-Bilt GW-2546

LEVER-HORSE OPC
(Superseded to 786-04003-0638)

$28.99

$

In Stock, Qty 10

0

26

Troy-Bilt GW-9199

PIN-PIVOT OPC LEVER

$6.49

$

In Stock, only 2 left!

0

27

Troy-Bilt GW-9514

RING-KLIP 5304-25

$6.99

$

In Stock, only 2 left!

0

28

Troy-Bilt GW-9387

SPRING-H/B LEVER
(Superseded to 732-04864A)

$6.99

$

In Stock, only 3 left!

0
