H5013 A2/C (FAHA) - Honda Multi-Purpose Tractor, Made in Japan (SN: FAHA-3100001 - FAHA-4099999) STEERING GEAR Parts Diagram

Multi-Purpose Tractor, Made in Japan

STEERING GEAR Parts Diagram

  • Title
1

Honda 32112-752-000

BRACKET, HARNESS CLIP (A)

$

$

Not available

2

Honda 53111-752-000

CASE, STEERING GEAR (UPPER)

$

$

Not available

3

Honda 53112-752-000

CASE, STEERING GEAR (LOWER)

$

$

Not available

4

Honda 53117-752-000

GASKET, STEERING CASE

Note: Use up to Frame SN 4100000.

$

$

Not available

5

Honda 53160-752-000

JOINT, ROD END

$

$

Not available

6

Honda 53167-752-003

JOINT, R. BALL (ER10)

$

$

Not available

7

Honda 53168-752-003

JOINT, L. BALL (ER10)
(Superseded to 53168-752-004)

$

$

Not available

8

Honda 53421-752-B30

ARM, PITMAN

$

$

Not available

9

Honda 53422-752-B30

PINION, STEERING

$

$

Not available

10

Honda 53423-752-003

BUSH, PINION HOLDER (A)

$18.99

$

Usually ships in 3-6 days

0

11

Honda 53424-752-003

BUSH, PINION HOLDER (B)

$

$

Not available

12

Honda 53427-752-B30

GEAR, STEERING

$

$

Not available

13

Honda 53428-752-000

GEAR, SUN (67T)

$

$

Not available

14

Honda 53429-752-010

GEAR, PLANETARY (19T)

$

$

Not available

15

Honda 53431-752-000

SHAFT, STEERING SECTOR

$

$

Not available

16

Honda 53521-752-B31

TIE ROD, FR.

$

$

Not available

17

Honda 90002-SA7-000

NUT, SELF-LOCK (10MM)
(Superseded to 90212-671-005)

$1.49

$

Usually ships in 3-6 days

0

18

Honda 90303-752-000

NUT, L. HEX. (10MM)

$3.99

$

Usually ships in 3-6 days

0

19

Honda 90401-HB6-000

WASHER, THRUST (15MM)

$

$

Not available

20

Honda 90421-961-000

WASHER, THRUST (25MM)

$7.99

$

Usually ships in 3-6 days

0

21

Honda 90459-107-000

WASHER, THRUST (12MM)

$1.99

$

Usually ships in 3-6 days

0

22

Honda 90501-752-000

WASHER (16.5X26X2)

$

$

Not available

23

Honda 91252-888-003

SEE PART DETAILS - SUP; OIL SEAL (25X38X7) (ARAI)
(Superseded to 91201-ZG9-U71)

$4.99

$

In Stock, Qty 7

0

24

Honda 91272-733-931

OIL SEAL (15X28X7)

$8.99

$

Usually ships in 3-6 days

0

25

Honda 93301-10040-0H

BOLT, HEX. (10X40)

$

$

Currently unavailable

26

Honda 94001-10080-0S

NUT, HEX. (10MM)

$1.99

$

Usually ships in 3-6 days

0

27

Honda 94301-14200

PIN, DOWEL (14X20)

$3.49

$

Usually ships in 3-6 days

0

28

Honda 94303-10160

PIN, DOWEL (10X16)

$3.49

$

Usually ships in 3-6 days

0

29

Honda 94510-12000

CIRCLIP, OUTER (12MM)

$2.49

$

In Stock, only 3 left!

0

30

Honda 94510-16000

CIRCLIP (OUTER) (16MM)

$1.49

$

Usually ships in 3-6 days

0

31

Honda 95701-06025-08

SEE PART DETAILS - PRI; BOLT, FLANGE (6X25)

$2.49

$

Usually ships in 3-6 days

0

32

Honda 95701-06028-07

BOLT, FLANGE (6X28)

$1.49

$

Usually ships in 3-6 days

0

33

Honda 95701-10030-08

SEE PART DETAILS - PRI; BOLT, FLANGE (10X30)

$2.99

$

In Stock, Qty 8

0

34

Honda 96100-60020-10

BEARING, RADIAL BALL (6002UU)

$16.99

$

Usually ships in 3-6 days

0

35

Honda 96100-62010-10

BEARING, RADIAL BALL (6201)

$

$

Not available
