GZ 7000 - RedMax Chainsaw (2008-12) CARBURETOR AIR FILTER Parts Diagram

Chainsaw

CARBURETOR AIR FILTER Parts Diagram

  • Title

1

RedMax 503202520

SCREW

$6.49

$

In Stock, Qty 10

0

2

RedMax 537213201

KNOB

$6.99

$

In Stock, only 1 left!

0

3

RedMax 537206602

RP AIR FILTER
(Superseded to 576486305)

Note: 44MY

$34.99

$

Usually ships in 3-10 days

0

3

RedMax 537206603

%AIR FILTER
(Superseded to 576486306)

Note: FELT

$22.99

$

In Stock, only 1 left!

0

4

RedMax 503203901

SCREW 4X46

$4.99

$

Usually ships in 3-10 days

0

5

RedMax 537205001

FILTER HOLDER

Note: . 6

$9.49

$

In Stock, Qty 5

0

6

RedMax 731231401

NUT

$2.49

$

In Stock, only 2 left!

0

7

RedMax 544199801

RP CARBURETOR
(Superseded to 580735801)

Note: . 8

$165.99

$

In Stock, Qty 6

0

8

RedMax 537213701

LEVER

$

$

Not available

9

RedMax 537204601

SLEEVE

$5.99

$

In Stock, only 1 left!

0

10

RedMax 537204501

FLANGE

Note: . 11

$11.99

$

Usually ships in 3-10 days

0

11

RedMax 503226503

NUT

$4.99

$

In Stock, only 4 left!

0

12

RedMax 537203701

HOSE

$12.99

$

In Stock, only 3 left!

0

13

RedMax 537204901

FLANGE

$13.99

$

In Stock, only 4 left!

0

14

RedMax 537204701

PARTITION

$20.99

$

Usually ships in 3-10 days

0

15

RedMax 503200216

SCREW

$4.99

$

In Stock, Qty 20+

0

16

RedMax 537204301

PIPE

$37.99

$

Usually ships in 3-10 days

0
