GX390 R1 QNB2 (GCANK) - Honda Engine, Made in Japan (SN: GCANK-1000001 - GCANK-9999999) CARBURETOR (1) Parts Diagram

Engine, Made in Japan

CARBURETOR (1) Parts Diagram

  • Title

1

Honda 16010-ZE2-812

SEE PART DETAILS - PRI; GASKET SET (INCLUDE 16173-001-004) (INCLUDES 16173-001-004)

$19.99

$

In Stock, Qty 12

0

2

Honda 16011-ZA0-931

VALVE SET, FLOAT (Honda Code 2059236).

$45.99

$

In Stock, only 1 left!

0

3

Honda 16013-ZA0-931

FLOAT SET (Honda Code 2059244).

$51.99

$

In Stock, only 1 left!

0

4

Honda 16015-ZE8-005

SEE PART DETAILS - PRI; CHAMBER SET, FLOAT (Honda Code 2089993).

$46.99

$

Usually ships in 3-6 days

0

5

Honda 16016-ZH7-W01

SEE PART DETAILS - PRI; SCREW SET (Honda Code 4219879). (CARBURETOR NO.)

$21.99

$

In Stock, only 1 left!

0

6

Honda 16024-ZE1-811

SCREW SET, DRAIN (Honda Code 1672187). (CARBURETOR NO.)

$10.99

$

In Stock, only 3 left!

0

7

Honda 16028-ZE0-005

SEE PART DETAILS - PRI; SCREW SET B (Honda Code 1441518).
(Superseded to 16028-ZK7-S91)

$13.99

$

In Stock, only 1 left!

0

7

Honda 16028-ZK7-S91

SEE PART DETAILS - PRI; SCREW SET

$13.99

$

In Stock, only 1 left!

0

8

Honda 16044-ZE3-W20

CHOKE SET (CARBURETOR NO.)

$37.99

$

Usually ships in 3-6 days

0

9

Honda 16100-ZF6-V01

SEE PART DETAILS - PRI; CARBURETOR ASSY. (BE85B B)

$129.99

$

In Stock, only 1 left!

0

10

Honda 16124-ZE0-005

SCREW, THROTTLE STOP (Honda Code 1441559).

$17.99

$

In Stock, only 1 left!

0

11

Honda 16166-ZF6-V00

NOZZLE, MAIN (CARBURETOR NO.)

$35.99

$

Usually ships in 3-6 days

0

12

Honda 16172-ZE3-W10

COLLAR, SET (Honda Code 3738358).

$10.99

$

Usually ships in 3-6 days

0

13

Honda 16173-001-004

GASKET, FUEL STRAINER CUP (Honda Code 0005652).

$7.49

$

In Stock, only 2 left!

0

15

Honda 16211-ZF6-000

INSULATOR, CARBURETOR

$21.99

$

In Stock, only 1 left!

0

17

Honda 16221-ZF6-800

SEE PART DETAILS - PRI; GASKET, CARBURETOR (Honda Code 3713161).

$2.49

$

In Stock, Qty 12

0

18

Honda 16223-ZE3-W00

GASKET, INSULATOR Use up to Engine SN 2949254.

$2.99

$

In Stock, Qty 6

0

19

Honda 16576-891-000

HOLDER, CABLE (Honda Code 0800466).

$5.49

$

In Stock, only 1 left!

0

20

Honda 16590-ZE2-812

SEE PART DETAILS - PRI; STAY ASSY., CHOKE CONTROL (REMOTE)

$47.99

$

Usually ships in 3-6 days

0

21

Honda 16594-883-010

SEE PART DETAILS - PRI; HOLDER, WIRE (Honda Code 2686558).

$9.49

$

In Stock, only 3 left!

0

23

Honda 16615-ZE2-810

SPRING, RETURN (Honda Code 2160000).

$2.99

$

Usually ships in 3-6 days

0

24

Honda 16953-ZE1-812

LEVER, VALVE (Honda Code 5140876).

$10.99

$

In Stock, Qty 10

0

25

Honda 16954-ZE1-812

SEE PART DETAILS - PRI; PLATE, LEVER SETTING (CARBURETOR NO.)

$4.49

$

In Stock, only 1 left!

0

26

Honda 16956-ZE1-811

SEE PART DETAILS - PRI; SPRING, PETCOCK LEVER (CARBURETOR NO.)

$4.49

$

Usually ships in 3-6 days

0

27

Honda 16957-ZE1-812

SEE PART DETAILS - PRI; GASKET, VALVE (Honda Code 3440708).

$4.49

$

In Stock, Qty 20+

0

28

Honda 16967-ZE0-811

CUP, FUEL STRAINER (Honda Code 1441583).

$23.99

$

In Stock, only 3 left!

0

29

Honda 90605-230-000

CIRCLIP (5MM) Use from Engine SN 2327377.

$4.49

$

In Stock, only 2 left!

0

30

Honda 93500-03006-0H

SEE PART DETAILS - PRI; SCREW, PAN (3X6) (Honda Code 0561654).

$1.49

$

In Stock, only 3 left!

0

31

Honda 93500-04006-0H

SEE PART DETAILS - PRI; SCREW, PAN (4X6) (Honda Code 0285627).

$1.49

$

In Stock, Qty 7

0

32

Honda 93893-05016-00

SCREW-WASHER (5X16) (Honda Code 0821512).

$1.49

$

Usually ships in 3-6 days

0

36

Honda 99101-ZH8-0880

SEE PART DETAILS - PRI; JET, MAIN (#88) Use up to Engine SN BE81B B.

Note: (Optional).

$8.49

$

In Stock, only 1 left!

0

36

Honda 99101-ZH8-0900

SEE PART DETAILS - PRI; JET, MAIN (#90) Use from Engine SN BE81B C.

Note: (Optional).

$8.49

$

In Stock, only 2 left!

0

36

Honda 99101-ZH8-0920

SEE PART DETAILS - PRI; JET, MAIN (#92) (Honda Code 5947163).

$8.49

$

In Stock, only 1 left!

0

37

Honda 99204-ZA0-0450

JET SET, PILOT (#45) (Honda Code 2060465).

$25.99

$

In Stock, only 1 left!

0
