GX240 HA (GC04) - Honda Engine, Made in Japan (SN: GC04-1000001 - GC04-1528199) 1/6 REDUCTION (HA) Parts Diagram

Engine, Made in Japan

1/6 REDUCTION (HA) Parts Diagram

  • Title

1

Honda 11500-ZE2-620

COVER ASSY., REDUCTION CASE (Honda Code 2025286).

$157.99

$

In Stock, only 1 left!

0

2

Honda 11521-ZE2-800

SEE PART DETAILS - PRI; GASKET, CHAIN CASE COVER (Honda Code 3678513).

$11.99

$

In Stock, only 1 left!

0

3

Honda 22103-ZE2-620

GEAR, PRIMARY DRIVE (17T) (Honda Code 2026284).

$61.99

$

Usually ships in 3-6 days

0

4

Honda 23220-ZE2-620

SEE PART DETAILS - SUP; COUNTERSHAFT (18/40T) (Honda Code 2026292).

Note: Use up to Engine SN 1165533.

$

$

Currently unavailable

4

Honda 23220-ZE2-621

SEE PART DETAILS - PRI; COUNTERSHAFT (Honda Code 3682044).

$183.99

$

Usually ships in 3-6 days

0

5

Honda 23710-ZE2-621

SHAFT, P.T.O. (H-TYPE) (Honda Code 3304573).

$230.99

$

Usually ships in 3-6 days

0

6

Honda 90401-ZE2-620

SHIM A (Honda Code 3499753).

Note: (Optional).

$1.99

$

Usually ships in 3-6 days

0

7

Honda 90402-ZE2-620

SHIM B (Honda Code 3499761).

Note: (Optional).

$1.99

$

Usually ships in 3-6 days

0

8

Honda 90473-842-000

WASHER (8MM) (Honda Code 0323295).

$1.99

$

In Stock, only 4 left!

0

9

Honda 90745-ZE2-600

KEY (6.3X6.3X43) (Honda Code 2027167).

$17.99

$

In Stock, only 1 left!

0

10

Honda 91201-890-003

OIL SEAL (30X46X8) (Honda Code 0756494).

$11.99

$

Usually ships in 3-6 days

0

11

Honda 90701-HC4-000

PIN, DOWEL (8X12) (Honda Code 2978443).

Note: Use from Engine SN 1342866.

$3.99

$

In Stock, only 2 left!

0

11

Honda 94301-08120

PIN A, DOWEL (8X12) (Honda Code 0069328).

Note: Use from Engine SN 1342866.

$2.99

$

Usually ships in 3-6 days

0

12

Honda 95701-08025-00

BOLT, FLANGE (8X25) (Honda Code 2545325).

$2.49

$

In Stock, Qty 5

0

13

Honda 95700-08040-00

SEE PART DETAILS - SUP; BOLT, FLANGE (8X40) (Honda Code 0671222).
(Superseded to 95701-08040-00)

$1.99

$

In Stock, Qty 6

0

13

Honda 95701-08040-00

SEE PART DETAILS - PRI; BOLT, FLANGE (8X40) (Honda Code 2298404).

$1.99

$

In Stock, Qty 6

0

14

Honda 96100-62060-00

BEARING, RADIAL BALL (6206) (Honda Code 0636118).

$30.99

$

In Stock, only 1 left!

0

15

Honda 96100-63020-00

SEE PART DETAILS - PRI; BEARING, RADIAL BALL (6302) (Honda Code 0834176).

$11.99

$

Usually ships in 3-6 days

0
