GT 1554 (14AK13CK710) - Cub Cadet 54" Garden Tractor (2005 & Before) Oil Pan & Lubrication Parts Diagram

54" Garden Tractor

Oil Pan & Lubrication Parts Diagram

  • Title

1

Cub Cadet KH-24-199-21-S

Kit, Oil Pan, Includes 2-13
(Superseded to KH-24-199-35-S)

$337.99

$

In Stock, only 1 left!

0

2

Cub Cadet KH-M-645025-S

Screw, Hx Flange, M6 -1.0 x 25
(Superseded to KH-25-086-395-S)

$2.49

$

In Stock, only 3 left!

0

3

Cub Cadet KH-M-631005

Washer, 6mm

$

$

Not available

4

Cub Cadet KH-24-393-37-S

Oil Pump Ass’y., Includes 5,6
(Superseded to KH-24-393-53-S)

$

$

Not available

5

Cub Cadet KH-24-153-01

O-Ring,

$

$

Not available

6

Cub Cadet KH-24-381-11-S

Tube, Oil Pick-up

$

$

Not available

7

Cub Cadet KH-24-162-26-S

Screen, Oil

$17.99

$

In Stock, only 1 left!

0

8

Cub Cadet KH-24-043-12

Kit, Governor Gear

$

$

Not available

9

Cub Cadet KH-12-380-01

Pin, Governor Regulating

$

$

Not available

10

Cub Cadet KH-24-448-02-S

Tab, Locking

$2.49

$

In Stock, Qty 20+

0

11

Cub Cadet KH-12-144-02

Shaft, Governor Gear

$

$

Not available

12

Cub Cadet KH-24-041-54-S

Gasket, Oil Pan
(Superseded to KH-24-041-66-S)

$25.99

$

In Stock, Qty 8

0

13

Cub Cadet KH-52-032-08

Seal, Oil
(Superseded to KH-25-032-06-S)

$10.99

$

In Stock, Qty 20+

0

14

Cub Cadet KH-24-422-03-S

Shim, Thrust

$

$

Not available

15

Cub Cadet KH-25-139-62-S

Plug, 3/8 Hex Ctsk

$3.49

$

In Stock, only 2 left!

0

16

Cub Cadet KH-24-755-52

Kit, Oil Cooler

$

$

Not available

17

Cub Cadet KH-24-136-05-S

Nipple, Oil Filter
(Superseded to KH-24-136-08-S)

$

$

Not available

18

Cub Cadet KH-24-594-24-S

Cooler, Oil

$

$

Not available

19

Cub Cadet KH-24-041-29

Gasket, Oil Filter Adapter
(Superseded to KH-24-041-88-S)

$5.49

$

In Stock, Qty 8

0

20

Cub Cadet KH-12-050-08

Filter, Oil
(Superseded to KH-12-050-01-S)

$13.99

$

In Stock, Qty 20+

0

21

Cub Cadet KH-24-086-16

Screw, Hx Flange, M8-1.25 x 45
(Superseded to KH-24-086-17-S)

$2.49

$

In Stock, Qty 5

0

22

Cub Cadet KH-24-086-17

Screw, Hx Flange, M8-1.25 x 45
(Superseded to KH-24-086-17-S)

$2.49

$

In Stock, Qty 5

0

23

Cub Cadet KH-25-139-57-S

Plug, Pipe, 3/8

$2.49

$

In Stock, only 3 left!

0
