GT 1554 (14AK13CK710) - Cub Cadet 54" Garden Tractor (2005 & Before) Electrical System Parts Diagram

54" Garden Tractor

Electrical System Parts Diagram

  • Title

1

Cub Cadet 17962

Plate, Switch

$4.99

$

In Stock, only 3 left!

0

2

Cub Cadet 629-04139

Harness Assembly
(Superseded to 629P04139)

$250.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 629-04142

Harness Assembly, Headlight
(Superseded to 629-04142A)

$25.99

$

In Stock, only 1 left!

0

4

Cub Cadet 710-0224

Screw, Hx. Wash. Hd. Tapp, 10-16 x .5
(Superseded to 910-0224)

$3.99

$

In Stock, Qty 20+

0

5

Cub Cadet 710-0227

Screw, Hx. Wash. Hd. Tapp, 8-18 x .5

$4.49

$

In Stock, Qty 20+

0

6

Cub Cadet 725-04022

Indicator/ Meter Hour
(Superseded to 925-04022B)

$146.99

$

In Stock, Qty 5

0

7

Cub Cadet 725-04039

Switch, Interlock
(Superseded to 925-04039)

$24.99

$

In Stock, Qty 7

0

8

Cub Cadet 725-04175

Switch, Electric PTO, Yellow Knob
(Superseded to 925-04175A)

$46.99

$

In Stock, only 4 left!

0

9

Cub Cadet 725-1303

Switch, Outer Seat Spring
(Superseded to 925-1303)

$6.49

$

In Stock, Qty 7

0

10

Cub Cadet 725-1439

Switch, Inner Seat Spring

$8.49

$

In Stock, Qty 10

0

11

Cub Cadet 725-2054

Key, Switch, Plastic
(Superseded to 925-2054A)

$17.99

$

In Stock, Qty 20+

0

12

Cub Cadet 726-0278

Plate, Insulator Boss

$6.99

$

In Stock, Qty 10

0

13

Cub Cadet 726-0279

Plate, Insulator

$3.99

$

In Stock, Qty 8

0

14

Cub Cadet 725-04227

Switch, Key/Module
(Superseded to 925-06119C)

$116.99

$

In Stock, Qty 20+

0

15

Cub Cadet 725-1648

Relay
(Superseded to 925-1648A)

$47.99

$

In Stock, Qty 7

0

16

Cub Cadet 725-1381

Fuse, 20 Amp
(Superseded to 925-1381)

$6.49

$

In Stock, Qty 11

0

17

Cub Cadet 725-04008

Fuse, 5 Amp

$

$

Not available

18

Cub Cadet 725-2003

Receptacle, Power 12V

$42.99

$

Usually ships in 3-6 days

0
