FL 1500 - Weed Eater Featherlite Blower, Type 7 Blower Assembly Type 7 Parts Diagram

Featherlite Blower, Type 7

Blower Assembly Type 7 Parts Diagram

  • Title

1

Poulan 530054429

Handle

$

$

Not available

2

Poulan 530054432

Isolator-Handle

$5.99

$

Usually ships in 3-10 days

0

3

Poulan 530016316

Nut

$

$

Not available

4

Poulan 530015810

Screw
(Superseded to 530016386)

$8.99

$

In Stock, only 1 left!

0

5

Poulan 530057102

Shroud

$13.99

$

Usually ships in 3-10 days

0

6

Poulan 530016349

Screw

$6.49

$

In Stock, only 1 left!

0

7

Poulan 530071472

Gasket-Carb. (Kit)

$

$

Not available

8

Poulan 530052333

Air Box

$

$

Not available

9

Poulan 530015158

Washer
(Superseded to 530015123)

$4.99

$

In Stock, only 4 left!

0

10

Poulan 530016349

Screw

$6.49

$

In Stock, only 1 left!

0

11

Poulan 530052332

Cover-Air Box

$3.49

$

In Stock, Qty 7

0

12

Poulan 545082301

Foam-Air Filter

$9.49

$

Usually ships in 3-10 days

0

13

Poulan 530016394

Screw

$

$

Not available

14

Poulan 530071629

Kit-Carburetor Ass'y. (C1U-W12A)

$

$

Not available

15

Poulan 530057725

Foam-Air Dam

$

$

Not available

16

Poulan 530016309

Screw

$5.99

$

Usually ships in 3-10 days

0

17

Poulan 530057634

Adaptor-Carb.

$12.99

$

Usually ships in 3-10 days

0

18

Poulan 530071472

Gasket-Cyl/Carb. Adaptor (Kit)

$

$

Not available

19

Poulan 530071472

O-ring-C'case/Shroud (Kit)

$

$

Not available

20

Poulan 530071680

Assy.-C'case & C'shaft

Note: (Incl. 21-23)

$38.99

$

Usually ships in 3-10 days

0

21

Poulan 530052344

Assy.-Crankshaft
(Superseded to 530071625)

$

$

Not available

22

Poulan 530012510

Assy.-Crankcase

Note: (Incl. 27-29)

$

$

Not available

23

Poulan 530015941

Retainer Ring (C'shaft)

$4.99

$

Usually ships in 3-10 days

0

24

Poulan 530054115

Assy.-Flywheel
(Superseded to 545221701)

$28.99

$

In Stock, only 1 left!

0

25

Poulan 530058942

Fan Housing

$12.99

$

Usually ships in 3-10 days

0

26

Poulan 530015810

Screw
(Superseded to 530016386)

$8.99

$

In Stock, only 1 left!

0

27

Poulan 530032125

Inner Bearing
(Superseded to 738210101)

$18.99

$

Usually ships in 3-10 days

0

28

Poulan 530019264

Seal-Crankcase

$7.49

$

In Stock, only 1 left!

0

29

Poulan 530055728

Bearing-Outer

$9.99

$

Usually ships in 3-10 days

0

30

Poulan 530071472

Seal-Cylinder (Kit)

$

$

Not available

31

Poulan 530039163

Ignition Module

$53.99

$

In Stock, only 1 left!

0

32

Poulan 530019182

Grommet-Ign. Module

$3.99

$

Usually ships in 3-10 days

0

33

Poulan 530016357

Screw

$6.49

$

In Stock, only 4 left!

0

34

Poulan 530069945

Kit-Connecting Rod Assy.
(Superseded to 530049817)

$13.99

$

Usually ships in 3-10 days

0

35

Poulan 530071833

Kit-Piston

Note: (Incl. 36 & 37)

$37.99

$

Usually ships in 3-10 days

0

36

Poulan 530015162

Wrist Pin Retainer

$6.49

$

In Stock, only 1 left!

0

37

Poulan 530055120

Piston Ring
(Superseded to 545154001)

$4.99

$

In Stock, only 2 left!

0

38

Poulan 530071785

Kit-Piston/Rod Assy.

Note: (Incl. 34,35)

$47.99

$

Usually ships in 3-10 days

0

39

Poulan 530015953

Screw

$6.49

$

In Stock, Qty 7

0

40

Poulan 530012500

Cylinder

$20.99

$

Usually ships in 3-10 days

0

41

Poulan 952030249

Spark Plug (RCJ-6Y)

$4.99

$

In Stock, Qty 20+

0

42

Poulan 530071472

Gasket-Muffler (kit)

$

$

Not available

43

Poulan 530071805

Kit-Muffler

Note: (incl. #42,44-46)

$21.99

$

In Stock, only 1 left!

0

44

Poulan 530016338

Bolt-Muffler

$3.99

$

In Stock, only 2 left!

0

45

Poulan 530071544

Kit-Spark Aresstor

$

$

Not available

46

Poulan 530015241

Screw

$3.99

$

Usually ships in 3-10 days

0

47

Poulan 530071472

Kit-Gasket

Note: (incl. 7,18,19,30).

$

$

Not available

Poulan 530164008

Manual

Note: Not Shown

$4.99

$

Usually ships in 3-10 days

0

Poulan 530059953

Decal-Start Inst.

Note: Not Shown

$2.49

$

Usually ships in 3-10 days

0
