EZ 4824 BF (966582401) - Husqvarna 48" Zero-Turn Mower (2010-03) Ignition System Parts Diagram

48" Zero-Turn Mower

Ignition System Parts Diagram

  • Title

1

Husqvarna 539130393

Cap, Fuel

$

$

Not available

2

Husqvarna 539130374

Fender, Lt

$93.99

$

In Stock, only 1 left!

0

3

Husqvarna 539130375

Fender, Rt

$

$

Not available

4

Husqvarna 522524801

Tank, Fuel

$

$

Not available

5

Husqvarna 539110432

Elbow, Tank
(Superseded to 532139277)

$8.99

$

In Stock, only 1 left!

0

6

Husqvarna 539110074

Hour Meter
(Superseded to 576179401)

$34.99

$

In Stock, Qty 6

0

7

Husqvarna 539130207

Control, Choke
(Superseded to 539102733)

$56.99

$

In Stock, Qty 5

0

8

Husqvarna 539102732

Cable, Throttle

$

$

Not available

9

Husqvarna 539107541

Switch, Ignition
(Superseded to 532175566)

$26.99

$

In Stock, only 4 left!

0

10

Husqvarna 539101768

Switch, Clutch
(Superseded to 582107601)

$28.99

$

In Stock, Qty 8

0

11

Husqvarna 539113792

Switch, Brake

$17.99

$

In Stock, Qty 12

0

12

Husqvarna 539112735

Plate, Control

$27.99

$

In Stock, only 1 left!

0

13

Husqvarna 539105245

Grommet, Rubber

$4.99

$

In Stock, Qty 11

0

14

Husqvarna 539102436

Battery
(Superseded to 579411601)

$

$

Not available

15

Husqvarna 539131209

Tie Down, Battery

$31.99

$

In Stock, Qty 5

0

16

Husqvarna 539116400

Terminal Cover

$3.99

$

Usually ships in 3-10 days

0

17

Husqvarna 539101080

Switch, Nc

$17.99

$

Usually ships in 3-10 days

0

18

Husqvarna 539101714

Solenoid

$26.99

$

Usually ships in 3-10 days

0

19

Husqvarna 539108461

Bolt 1/4-20 X 1/2 Hwst

$4.99

$

In Stock, Qty 5

0

20

Husqvarna 539112740

Decal, Console

$

$

Not available

21

Husqvarna 539990411

Screw 10-24 X 1/2 Slt Hd

$3.99

$

Usually ships in 3-10 days

0

22

Husqvarna 539976978

Nut 1/4-20 Hex Nyloc
(Superseded to 582478602)

$2.49

$

In Stock, Qty 20+

0

23

Husqvarna 539976977

Nut 10-24 Hex Nyloc

$

$

Not available

24

Husqvarna 539110673

Screw 10-12 X 3/4 Wsh Hd

$4.99

$

Usually ships in 3-10 days

0

25

Husqvarna 539111229

Screw 1/4-20 X 5/8 Btn Skt

$3.99

$

Usually ships in 3-10 days

0

26

Husqvarna 539991034

Screw 10-24 X 5/8 Wsh Hd

$3.99

$

Usually ships in 3-10 days

0

27

Husqvarna 539990316

Rhsnb 5/16-18 X 3/4
(Superseded to 595901601)

$3.99

$

In Stock, Qty 20+

0

28

Husqvarna 539112899

Nut 5/16-18 Flange Nyloc
(Superseded to 594944401)

$6.99

$

In Stock, Qty 20+

0

29

Husqvarna 539110056

Lens, Lt
(Superseded to 539110457)

$7.49

$

In Stock, only 2 left!

0

Husqvarna 539110057

Lens, Rt
(Superseded to 539110453)

$7.49

$

Usually ships in 3-10 days

0

30

Husqvarna 539110455

Lens Rim, Lt

$6.49

$

In Stock, only 1 left!

0

Husqvarna 539110451

Lens Rim, Rt

$6.49

$

In Stock, only 1 left!

0

31

Husqvarna 522559101

Shield, Heat

$37.99

$

Usually ships in 3-10 days

0

32

Husqvarna 539102759

Insulator

$4.99

$

In Stock, only 2 left!

0

33

Husqvarna 539990053

Washer 1/4 Int Tooth Lk

$3.99

$

In Stock, only 3 left!

0

Husqvarna 539103306

Positive Cable, Long
(Superseded to 586108201)

Note: Not Shown

$10.99

$

In Stock, only 2 left!

0

Husqvarna 539110068

Battery Cable Negative

Note: Not Shown

$9.49

$

Usually ships in 3-10 days

0

Husqvarna 515980501

Harness, Wiring
(Superseded to 580798101)

Note: Not Shown

$145.99

$

Usually ships in 3-10 days

0
