EY280B71810 (EY28) - Subaru Robin Engine 301 Intake & Exhaust Parts Diagram

Engine

301 Intake & Exhaust Parts Diagram

  • Title

10

Subaru Robin 234-31602-01

CAM SHAFT CP

Note: End Code: 2981. Remarks: L=200 25DX60L. Interchangable with 234-31602-11.

$263.08

$

Usually ships in 2-12 days

0

10

234-31602-11

CAM SHAFT CP

Note: Start Code: 2982. Remarks: L=200 25DX60L.

$

$

Not available

20

Subaru Robin 234-31602-03

CAM SHAFT

Note: End Code: 2981. Remarks: L=200 25DX60L. Interchangable with 234-31602-13.

$140.58

$

Usually ships in 2-12 days

0

20

Subaru Robin 234-31602-13

CAM SHAFT

Note: Start Code: 2982. Remarks: L=200 25DX60L.

$128.74

$

Usually ships in 2-12 days

0

30

Subaru Robin 234-33201-03

CAMSHAFT GEAR

Note: Remarks: 30.2DX96DX21B N=38.

$127.21

$

Usually ships in 2-12 days

0

40

Subaru Robin 032-30300-10

WOODRUFF KEY

Note: Remarks: 3BX6HX16D.

$4.49

$

Usually ships in 2-12 days

0

50

Subaru Robin 234-33301-03

TAPPET

$16.99

$

Usually ships in 2-12 days

0

60

Subaru Robin 227-33601-03

VALVE SPRING

Note: Remarks: 20DX2.3DX37L N=8.

$4.49

$

Usually ships in 2-12 days

0

70

Subaru Robin 234-33701-03

SPRING RETAINER

$2.99

$

In Stock, only 2 left!

0

80

Subaru Robin 234-33401-03

INTAKE VALVE

Note: Remarks: 31.5DX6.5DX91.4L.

$32.99

$

Usually ships in 2-12 days

0

90

Subaru Robin 234-33501-03

EXHAUST VALVE

Note: Remarks: 28.5DX6.5DX91.4L.

$52.99

$

Usually ships in 2-12 days

0

100

Subaru Robin 023-03001-70

SPACER

Note: Remarks: 30.3DX40DX0.6T.

$

$

Not available

101

Subaru Robin 023-03001-80

SPACER

Note: Remarks: 30.3DX40DX0.8T.

$1.49

$

Usually ships in 2-12 days

0

102

Subaru Robin 023-03001-90

SPACER

Note: Remarks: 30.3DX40DX1.0T.

$1.49

$

Usually ships in 2-12 days

0

110

Subaru Robin 005-30073-51

KEY

$7.49

$

Usually ships in 2-12 days

0

120

Subaru Robin 020-00800-20

WASHER

Note: Remarks: 8.5DX35DX4.5T.

$2.49

$

Usually ships in 2-12 days

0

130

Subaru Robin 001-13081-60

BOLT & WASHER AY

$0.99

$

Usually ships in 2-12 days

0

310

Subaru Robin 234-30210-01

MUFFLER CP

$123.46

$

Usually ships in 2-12 days

0

320

Subaru Robin 234-34201-01

MUFFLER COVER CP

$64.99

$

Usually ships in 2-12 days

0

330

Subaru Robin 234-35302-01

MUFFLER BRACKET

$5.59

$

Usually ships in 2-12 days

0

340

234-35201-11

GASKET CP(EXHAUST)

Note: Start Code: 5570. End Code: 5599. Remarks: T=1.5 26D 9DX52P.

$

$

Not available

340

Subaru Robin 234-35201-01

GASKET CP(EXHAUST)

Note: End Code: 5569. Remarks: T=1.5 26D 9DX52P.

$7.49

$

Usually ships in 2-12 days

0

340

Subaru Robin 234-35201-21

GASKET CP(EXHAUST)

Note: Start Code: 5600.

$7.49

$

Usually ships in 2-12 days

0

350

Subaru Robin 017-00800-30

NUT

Note: Start Code: 4962. Remarks: M8X1.25X6.5H.

$2.49

$

Usually ships in 2-12 days

0

350

Subaru Robin 002-19080-00

NUT

Note: End Code: 4961.

$3.49

$

In Stock, only 2 left!

0

360

Subaru Robin 011-00600-10

FLANGE BOLT

Note: Remarks: M6X1.0X14DX8L.

$2.49

$

In Stock, Qty 8

0

370

Subaru Robin 011-00600-10

FLANGE BOLT

Note: Remarks: M6X1.0X14DX8L.

$2.49

$

In Stock, Qty 8

0

375

Subaru Robin 011-00600-20

FLANGE BOLT

Note: Remarks: M6X1.0X14DX12L.

$2.49

$

In Stock, only 4 left!

0

540

Subaru Robin 234-32901-03

INSULATOR

$6.49

$

Usually ships in 2-12 days

0

550

Subaru Robin 234-35901-13

GASKET (INSULATOR)

Note: Start Code: 5600. Remarks: T=0.5 28D 6.5DX46P.

$2.49

$

Usually ships in 2-12 days

0

550

Subaru Robin 234-35901-03

GASKET (INSULATOR)

Note: End Code: 5599. Remarks: T=0.3 28D 6.5DX46P.

$2.49

$

Usually ships in 2-12 days

0

560

Subaru Robin 234-35902-03

GASKET2(INSULATOR)

Note: Remarks: T=0.2 25D 6.5DX46P.

$1.49

$

In Stock, Qty 5

0

570

Subaru Robin 002-17060-00

NUT

$0.99

$

Usually ships in 2-12 days

0

575

Subaru Robin 003-20060-00

SPRING WASHER

$0.99

$

Usually ships in 2-12 days

0

675

Subaru Robin 234-46101-01

KNOB CP

$5.20

$

Usually ships in 2-12 days

0

850

Subaru Robin 085-10800-00

RUBBER PIPE

Note: Remarks: 8DX11D.

$23.99

$

In Stock, only 1 left!

0
