Evolution (5900858) - Ferris Evolution Series 52" Stand-On Mower, 26hp Kawasaki Hydraulics Group Parts Diagram

Evolution Series 52" Stand-On Mower, 26hp Kawasaki

Hydraulics Group Parts Diagram

  • Title

1

Ferris 1719168

FILTER, OIL
(Superseded to 1719168X1)

$26.99

$

In Stock, Qty 20+

0

2

Ferris 5021164

CLAMP, #10 HOSE, STAINLESS
(Superseded to 5021164SM)

$3.99

$

In Stock, only 1 left!

0

3

Ferris 5102257

CLAMP, HOSE, EXTERNAL, 3/4

$

$

Currently unavailable

4

Ferris 5022709

FITTING, #8 JIC - #10 O-RING, 45 DEG.
(Superseded to 5022709SM)

$46.99

$

In Stock, only 2 left!

0

5

Ferris 5022920

FITTING, TEE, 1/2 HOSE
(Superseded to 5022920SM)

$18.99

$

Usually ships in 2-12 days

0

6

Ferris 5022922

CLAMP, #4 HOSE, STAINLESS
(Superseded to 5022922SM)

$3.49

$

In Stock, only 1 left!

0

7

Ferris 5023096

FILTER HEAD, HYDRAULIC
(Superseded to 5023096SM)

$52.99

$

Usually ships in 2-12 days

0

8

Ferris 5023267

ADAPTER, 90 DEG, 9/16-3/8 BARB
(Superseded to 5023267SM)

$30.99

$

Usually ships in 2-12 days

0

9

Ferris 5023268

CLAMP, HOSE
(Superseded to 5023268SM)

$3.49

$

Usually ships in 2-12 days

0

10

Ferris 5023338

FITTING, #8 JIC - #8 O-RING, 45 DEG.
(Superseded to 5023338SM)

$36.99

$

Usually ships in 2-12 days

0

11

Ferris 5023346

ADAPTER, 90 DEG, 9/16-5/8 BARB
(Superseded to 5023346SM)

$42.99

$

Usually ships in 2-12 days

0

12

Ferris 5025154

WASHER, 1/4 SAE
(Superseded to 84007033)

$4.49

$

Usually ships in 2-12 days

0

13

Ferris 5025155

WASHER, 5/16" SAE

$

$

Currently unavailable

14

Ferris 5025169

WASHER, 1/4 LOCK
(Superseded to 5025169FS)

$3.99

$

Usually ships in 2-12 days

0

15

Ferris 5025534

BOLT,HEX FLG, SER GD8 3/8-16X1, PATCH

$

$

Not available

16

Ferris 5025392

NUT, 5/16-18 HEX NYLOCK FLANGE
(Superseded to 5025392FS)

$3.49

$

Usually ships in 2-12 days

0

17

Ferris 5061712

TANK, HYDRAULIC, ASSEMBLY
(Superseded to 5061712SM)

$154.99

$

In Stock, Qty 6

0

18

Ferris 5100017

CAP, HYDRAULIC, SHIELDED VENT
(Superseded to 5100017SM)

$23.99

$

In Stock, only 1 left!

0

19

Ferris 5100370

FITTING, 9/16 O-RING-1/2" HOSE, 90 DEG
(Superseded to 5100370YP)

$18.99

$

Usually ships in 2-12 days

0

20

Ferris 5102106

HOSE ASM,RH, LH PUMP PORT BOT MOTOR PORT

$151.99

$

Usually ships in 2-12 days

0

21

Ferris 5102108

HOSE ASM,LH, LH PUMP PORT BOT MOTOR PORT

$151.99

$

Usually ships in 2-12 days

0

22

Ferris 5102191

PUMP, 12CC-LH,HGEAR (PK-2HBQ-LV1X-XXXX)

$1244.99

$

Usually ships in 2-12 days

0

23

Ferris 5102192

PUMP, 12CC-RH, HGEAR(PK-2KBQ-L81X-XXXX)

$1215.99

$

Usually ships in 2-12 days

0

24

Ferris 5101583

WHEEL MOTOR, HGM-15P-7131

$3036.99

$

Usually ships in 2-12 days

0

25

Ferris 5101693

FITTING, BEADED TEE, 1/2 X 1/2 X 1/2, YZ
(Superseded to 5101693YP)

$21.99

$

Usually ships in 2-12 days

0

26

Ferris 5101721

OIL COOLER, .75 X 11.0 X 24 PLATES
(Superseded to 5101721FS)

$130.99

$

Usually ships in 2-12 days

0

27

Ferris 5101727

HOSE, OIL SUPPLY, RES-FILTER

$22.99

$

Usually ships in 2-12 days

0

28

Ferris 5025010X6

BOLT, 1/4-20 X 3/4 GD5 YZ
(Superseded to 5025010X6SM)

$3.99

$

In Stock, Qty 20+

0

29

Ferris 5025011X8

BOLT, 5/16-18 X 1 GD5 YZ
(Superseded to 5025011X8FS)

$3.49

$

In Stock, Qty 17

0

30

Ferris 5025015X10

BOLT, 7/16-14 X 1-1/4 GD5 YZ

$

$

Currently unavailable

31

Ferris 5050857X17P5

HOSE, 1/2" PUSH-ON, 17.50"

$10.99

$

Usually ships in 2-12 days

0

32

Ferris 5050857X8P5

HOSE, 1/2" PUSH-ON, 8.50"

$10.99

$

Usually ships in 2-12 days

0

33

Ferris 5050860X12

HOSE, 3/8" PUSH-LOCK, 12.00"

$10.99

$

Usually ships in 2-12 days

0

34

Ferris 5050860X17P25

HOSE, 3/8" PUSH-LOCK, 17.25

$

$

Currently unavailable

35

Ferris 5050857X3P5

HOSE, 1/2" PUSH-ON, 3.50"

$

$

Currently unavailable

36

Ferris 5050860X42

HOSE, 3/8" PUSH-LOCK, 42.00"

$43.99

$

Usually ships in 2-12 days

0

37

Ferris 5050860X8P5

HOSE, 3/8" PUSH-LOCK, 8.50"
(Superseded to 5050860X8P5SM)

$7.49

$

Usually ships in 2-12 days

0

38

Ferris 5102054

FITTING, 45 ELBOW, 1/2" HOSE TO 9/16 O R
(Superseded to 5102054FS)

$31.99

$

Usually ships in 2-12 days

0

39

Ferris 5025203X16

PIN, COTTER, 1/8 X 2" (SV)
(Superseded to 5025203X16SM)

$3.99

$

Usually ships in 2-12 days

0

40

Ferris 5023091X1

WOODRUFF KEY (SV)

$11.99

$

Usually ships in 2-12 days

0

41

Ferris 5101583X1

NUT, CASTLE, 3/4-20

Note: - TORQUE TO 115ft LBS. (156 Nm)

$

$

Not available

42

Ferris 5023118

FITTING, ELBOW, 3/8" (SV)
(Superseded to 5023118SM)

$7.99

$

Usually ships in 2-12 days

0

43

Ferris 1726400

BUSHING-FUEL TANK RED RUBBER
(Superseded to 1726400FS)

$11.99

$

In Stock, only 2 left!

0

44

Ferris 5023121

GROMMET (SV)
(Superseded to 5023121SM)

$15.99

$

Usually ships in 2-12 days

0

45

Ferris 5023119

FITTING, ELBOW, 5/8" (SV)

$

$

Currently unavailable

46

Ferris 5025533

NUT, HEX, 7/16-14, SER, FLG, GD5, YZ
(Superseded to 5025533FS)

$2.99

$

Usually ships in 2-12 days

0

47

Ferris 5050861X36

WIRE LOOM, 5/8 ID 36" LONG

$3.49

$

Usually ships in 2-12 days

0

48

Ferris 5025391

NUT, 1/4-20 HEX NYLOCK FLANGE
(Superseded to 5025391FS)

$3.99

$

In Stock, Qty 20+

0
