E1-12K801 (312-8) - Toro Garden Tractor (1988) ENGINES Parts Diagram

Garden Tractor

ENGINES Parts Diagram

  • Title

1

Toro 113489

Engine 16HP-Onan P-216-316-8 Only

$

$

Currently unavailable

Toro 114160

Engine 12HP-Kohler M-12-S 312-8 Only

$

$

Currently unavailable

2

Toro 113875

Engine Plate
(Superseded to 116772)

$

$

Not available

3

Toro 908036

BOLT
(Superseded to 323-8)

$1.49

$

In Stock, Qty 20+

0

4

Toro 915663

NUT
(Superseded to 3296-39)

$2.99

$

In Stock, Qty 8

0

5

Toro 908035

Bolt
(Superseded to 323-7)

$2.99

$

In Stock, Qty 20+

0

9

Toro 908036

BOLT
(Superseded to 323-8)

$1.49

$

In Stock, Qty 20+

0

10

Toro 915663

NUT
(Superseded to 3296-39)

$2.99

$

In Stock, Qty 8

0

11

Toro 908034

BOLT
(Superseded to 323-6)

$2.49

$

In Stock, Qty 20+

0

12

Toro 920083

LOCKWASHER
(Superseded to 3253-21)

$0.99

$

In Stock, Qty 10

0

Toro 114213

X-REF 114893
(Superseded to 114893)

$

$

Not available

Toro 908034

BOLT
(Superseded to 323-6)

$2.49

$

In Stock, Qty 20+

0

Toro 915663

NUT
(Superseded to 3296-39)

$2.99

$

In Stock, Qty 8

0
