DX 254 (966651203) - Dixon 54" Zero-Turn Mower (2013-01) IGNITION SYSTEM Parts Diagram

54" Zero-Turn Mower

IGNITION SYSTEM Parts Diagram

  • Title

1

Dixon 584280402

No Description Available

$376.99

$

Usually ships in 3-10 days

0

2

Dixon 584280302

No Description Available
(Superseded to 589997302)

$423.99

$

Usually ships in 3-10 days

0

3

Dixon 529280202

PANEL, CONTROL GAS, GRAY
(Superseded to 592979103)

$31.99

$

Usually ships in 3-10 days

0

4

Dixon 574514001

TIMER, SEAT

$120.99

$

In Stock, only 1 left!

0

5

Dixon 532401763

No Description Available
(Superseded to 594919101)

$24.99

$

In Stock, Qty 6

0

6

Dixon 574455401

SWITCH, IGNITION, INDAK

$34.99

$

Usually ships in 3-10 days

0

7

Dixon 539131627

SWITCH, PTO 10 AMP
(Superseded to 597520401)

$100.99

$

In Stock, Qty 5

0

8

Dixon 574455501

KEY, IGNITION

$6.99

$

Usually ships in 3-10 days

0

9

Dixon 574206901

No Description Available
(Superseded to 531077202)

$31.99

$

In Stock, Qty 8

0

10

Dixon 574207002

No Description Available

$66.99

$

Usually ships in 3-10 days

0

11

Dixon 539132624

KNOB - SHIFT

$7.99

$

In Stock, Qty 6

0

12

Dixon 539102436

OBSOLETE - BATTERY, 12 V 330 AMP TBR
(Superseded to 579411601)

$

$

Not available

13

Dixon 575018101

CAP, FUEL
(Superseded to 575018103)

$34.99

$

Usually ships in 3-10 days

0

14

Dixon 576618101

VALVE.FUEL.CHECK

$25.99

$

In Stock, Qty 13

0

15

Dixon 539102679

FUEL VALVE

$56.99

$

In Stock, only 2 left!

0

16

Dixon 522718701

CABLE, POSITIVE, 55"

$26.99

$

In Stock, only 2 left!

0

17

Dixon 522710701

CABLE, NEG, 55"

$34.99

$

Usually ships in 3-10 days

0

18

Dixon 539103178

OBSOLETE - CAP IGNITION NUT

$4.99

$

Usually ships in 3-10 days

0

19

Dixon 539912222

HOSE CLAMP

$4.99

$

In Stock, only 1 left!

0

20

Dixon 575436501

CLAMP, HOSE

$6.49

$

In Stock, only 4 left!

0

21

Dixon 577103901

No Description Available

$14.99

$

Usually ships in 3-10 days

0

22

Dixon 577103902

No Description Available
(Superseded to 587044838)

$6.99

$

Usually ships in 3-10 days

0

23

Dixon 576660601

HOSE, VAPOR 3/16 X 39"

$

$

Not available

24

Dixon 576660603

HOSE, 3/16" VAPOR, 21"

$

$

Not available

25

Dixon 576660604

HOSE, VAPOR 3/16 X 30"

$13.99

$

Usually ships in 3-10 days

0

26

Dixon 576547701

ASSEMBLY, VAPOR LINE

$43.99

$

Usually ships in 3-10 days

0

27

Dixon 539102759

INSULATOR

$4.99

$

In Stock, only 2 left!

0

28

579579702

No Description Available

$

$

Not available

29

Dixon 577104002

BRACKET,FUEL VALVE, BLACK

$15.99

$

Usually ships in 3-10 days

0

30

Dixon 510029902

BRACKET, BATTERY, BLK

$84.99

$

Usually ships in 3-10 days

0

31

Dixon 510030001

BRACKET, BATTERY MOUNT

$51.99

$

In Stock, only 1 left!

0

32

Dixon 510064001

HOOK, "J"

$

$

Not available

33

Dixon 574206602

No Description Available

$3.49

$

In Stock, only 1 left!

0

34

Dixon 539105245

RUBBER GROMMET

$4.99

$

In Stock, Qty 12

0

35

Dixon 576618201

GROMMET, CHECK VALVE
(Superseded to 584648201)

$4.99

$

In Stock, Qty 5

0

36

Dixon 539105974

OBSOLETE - RUBBER GROMMET

$

$

Not available

37

Dixon 525865401

No Description Available

$34.99

$

Usually ships in 3-10 days

0

38

Dixon 539990580

HCS 1/4C X 3/4 HCS

$3.99

$

Usually ships in 3-10 days

0

39

Dixon 539990316

BOLT 5/16C X 3/4" CARRIAGE
(Superseded to 595901601)

$3.99

$

In Stock, Qty 20+

0

40

Dixon 574822701

SCR #10-24 X .75 SKT HD BLK

$4.99

$

In Stock, Qty 6

0

41

Dixon 539114341

SCR #10-24 X 3/8 SKT HD BLK OX

$4.99

$

In Stock, only 3 left!

0

42

Dixon 539990997

WING NUT 1/4

$3.49

$

Usually ships in 3-10 days

0

43

Dixon 539112899

5/16-18 NYLOC FLANGE NUT
(Superseded to 594944401)

$6.99

$

In Stock, Qty 20+

0

44

Dixon 539108120

JAM NUT 1/4C
(Superseded to 582478602)

$2.49

$

In Stock, Qty 20+

0

45

Dixon 539976977

NUT 10-24 NYLOC

$

$

Not available

46

Dixon 539990598

WASHER 1/4 FLAT

$

$

Not available
