CZT 60 L (967943701-00) - RedMax 60" Zero-Turn Riding Mower (2018-09) IGNITION SYSTEM Parts Diagram

60" Zero-Turn Riding Mower

IGNITION SYSTEM Parts Diagram

  • Title

1

RedMax 589997302

FUEL.TANK.ASM.LH.PZ.BLACK.18

$423.99

$

Usually ships in 3-10 days

0

2

RedMax 590026002

FUEL TANK ASSY RH. PZ. BLACK.

$

$

Not available

3

RedMax 529280203

PANEL, CONTROL GAS BLACK

$

$

Not available

4

RedMax 574514001

TIMER, SEAT

$120.99

$

In Stock, only 1 left!

0

5

RedMax 586161801

GUAGE.SRVCMNDR.HRMTR.
(Superseded to 594919101)

$24.99

$

In Stock, Qty 6

0

6

RedMax 574455401

SWITCH, IGNITION, INDAK

$34.99

$

Usually ships in 3-10 days

0

7

RedMax 582107602

RP SWITCH.PTO.TERMINAL.STD.RED
(Superseded to 582107601)

$28.99

$

In Stock, only 4 left!

0

8

RedMax 574455501

KEY, IGNITION

$6.99

$

Usually ships in 3-10 days

0

9

RedMax 589608201

THROTTLE CABLE ASSY THROTTLE C

$56.99

$

Usually ships in 3-10 days

0

10

RedMax 574206901

CABLE, CHOKE, 48"
(Superseded to 574206905)

$36.99

$

Usually ships in 3-10 days

0

11

RedMax 539132624

KNOB - SHIFT

$7.99

$

In Stock, Qty 6

0

12

RedMax 539102436

BATTERY, 12 V 330 AMP
(Superseded to 579411601)

$

$

Not available

13

RedMax 575018101

CAP, FUEL

$21.99

$

Usually ships in 3-10 days

0

14

RedMax 576618101

VALVE.FUEL.CHECK

$25.99

$

In Stock, Qty 13

0

15

RedMax 525865401

FITTING, FUEL

$34.99

$

Usually ships in 3-10 days

0

16

RedMax 539102679

FUEL VALVE

$56.99

$

In Stock, only 2 left!

0

17

RedMax 587593401

HOSE.ASM.VAPOR.LINE.21-30-39

$17.99

$

Usually ships in 3-10 days

0

18

RedMax 577150501

ASSEMBLY, FUEL LINE

$48.99

$

Usually ships in 3-10 days

0

19

RedMax 539912222

HOSE CLAMP

$4.99

$

In Stock, only 1 left!

0

20

RedMax 575436501

CLAMP, HOSE

$6.49

$

In Stock, only 4 left!

0

21

RedMax 587044822

HOSE.1/4".LOW.PERM.FUEL.LN.22"

$11.99

$

In Stock, Qty 9

0

22

RedMax 587044838

HOSE.1/4".LOW.PERM.FUEL.LN.38"

$6.99

$

Usually ships in 3-10 days

0

23

RedMax 587044537

NEEDS DESCRIPTION

$

$

Currently unavailable

24

RedMax 587044521

HOSE.3/16".VAPOR.LINE.21"LGTH

$2.99

$

Usually ships in 3-10 days

0

25

RedMax 587044530

HOSE.3/16".VAPOR.LINE.30"LGTH

$

$

Not available

26

RedMax 522718701

CABLE, POSITIVE, 55"

$26.99

$

In Stock, only 2 left!

0

27

RedMax 522710701

CABLE, NEG, 55"

$34.99

$

Usually ships in 3-10 days

0

28

RedMax 539103178

CAP IGNITION NUT
(Superseded to 539115739)

$4.99

$

Usually ships in 3-10 days

0

29

RedMax 539102759

INSULATOR

$4.99

$

In Stock, only 2 left!

0

30

RedMax 532435395

COVER.TERMINAL.BATTERY

$6.49

$

In Stock, only 2 left!

0

31

RedMax 587181404

BRACKET.VALVE.PNT.BLACK.X431

$3.99

$

Usually ships in 3-10 days

0

32

RedMax 510029902

BRACKET, BATTERY, BLK

$84.99

$

Usually ships in 3-10 days

0

33

RedMax 593634404

Brackets

$6.49

$

Usually ships in 3-10 days

0

34

RedMax 510064001

HOOK, "J"
(Superseded to 510064002)

$3.99

$

In Stock, only 1 left!

0

35

RedMax 539105245

RUBBER GROMMET

$4.99

$

In Stock, Qty 12

0

36

RedMax 576618201

GROMMET, CHECK VALVE
(Superseded to 584648201)

$4.99

$

In Stock, Qty 5

0

37

RedMax 539105974

RUBBER GROMMET

$

$

Not available

38

RedMax 579579701

LOOM SPLIT 5/8, 32"

$3.49

$

Usually ships in 3-10 days

0

39

RedMax 574206602

TEE, FUEL LINE 3/16"

$3.49

$

In Stock, only 1 left!

0

40

RedMax 539990997

WING NUT 1/4

$3.49

$

Usually ships in 3-10 days

0

41

RedMax 539990580

HCS 1/4C X 3/4 HCS

$3.99

$

Usually ships in 3-10 days

0

42

RedMax 539990316

BOLT 5/16C X 3/4" CARRIAGE
(Superseded to 595901601)

$3.99

$

In Stock, Qty 20+

0

43

RedMax 574822701

SCR #10-24 X .75 SKT HD BLK

$4.99

$

In Stock, Qty 6

0

44

RedMax 539114341

SCR #10-24 X 3/8 SKT HD BLK OX

$4.99

$

In Stock, only 3 left!

0

45

RedMax 539976977

NUT 10-24 NYLOC
(Superseded to 596040801)

$3.99

$

In Stock, Qty 20+

0

46

RedMax 539112899

5/16-18 NYLOC FLANGE NUT
(Superseded to 594944401)

$6.99

$

In Stock, Qty 20+

0

47

RedMax 539108120

JAM NUT 1/4C (2 2 PW01)

$3.99

$

Usually ships in 3-10 days

0

48

RedMax 539990598

WASHER 1/4 FLAT
(Superseded to 597338501)

$14.99

$

In Stock, Qty 20+

0

RedMax 589670101

HARNESS.MAIN.PZ.PTO.START.RELA

Note: NOT SHOWN

$265.99

$

Usually ships in 3-10 days

0

RedMax 532409615

RELAY HARNESS.SEALED

Note: NOT SHOWN

$34.99

$

Usually ships in 3-10 days

0
