CV 48 (970465201) - RedMax 48" Stand-On Mower, Kawasaki FX (2020-02) HYDRAULIC PUMP - MOTOR Parts Diagram

48" Stand-On Mower, Kawasaki FX

HYDRAULIC PUMP - MOTOR Parts Diagram

  • Title

1

RedMax 539114662

SHIELD, DUST
(Superseded to 596394601)

Note: "Shield, Dust"

$3.99

$

In Stock, only 3 left!

0

2

RedMax 574975601

BUSHING, PIVOT

Note: "Bushing, Pivot"

$4.99

$

Usually ships in 3-10 days

0

3

RedMax 574891104

ARM, IDLER W/BEARING

Note: "Arm, Idler w/Bearings"

$159.99

$

Usually ships in 3-10 days

0

4

RedMax 539976688

IDLER PULLEY
(Superseded to 596739801)

Note: "Pulley, Idler 4"""

$34.99

$

In Stock, only 2 left!

0

5

RedMax 510262201

SHIELD, DUST
(Superseded to 596840301)

Note: "Shield, Dust"

$22.99

$

In Stock, Qty 13

0

6

RedMax 596789601

Bolts

Note: Bolt 1/2-13 x 3.0 Gr. 5

$4.99

$

Usually ships in 3-10 days

0

7

RedMax 595901401

Bolts

Note: Bolt 3/8-16 x 2 Gr. 5

$3.99

$

In Stock, Qty 6

0

8

RedMax 525435601

PIVOT, IDLER

Note: "Pivot, Idler"

$8.99

$

In Stock, only 4 left!

0

9

RedMax 510254502

NEEDS DESCRIPTION

Note: "Shield, Dust"

$4.99

$

Usually ships in 3-10 days

0

10

RedMax 521996502

GSPW Nuts

Note: Nut 3/8-16 Hex Flange Nylok

$3.99

$

In Stock, Qty 20+

0

11

RedMax 595316401

Washers

Note: Washer

$3.99

$

In Stock, Qty 20+

0

12

RedMax 521991102

NUT 1/2-13 HEX FLANGE NYLOK CL

Note: Nut 1/2-13 Hex Flange Nylok

$4.99

$

In Stock, Qty 7

0

13

RedMax 596240801

GSPW Bolts

Note: Eyebolt 5/16 x 3-1/2

$4.99

$

Usually ships in 3-10 days

0

14

RedMax 596039201

GSPW Hardware

Note: Nut 5/16-18 Serrated Flange

$3.99

$

In Stock, Qty 20+

0

15

RedMax 582480403

V-BELT GROUND DRIVE 79.52" STA

Note: Belt

$56.99

$

In Stock, only 1 left!

0

16

RedMax 577437201

SPRING, PUMP

Note: "Spring, Extension"

$8.99

$

In Stock, only 2 left!

0

17

RedMax 589398301

PULLEY PUMP, 5 INCH

Note: "Pulley, Pump, 5"""

$51.99

$

Usually ships in 3-10 days

0
