CS 2137 - Jonsered Chainsaw (2004-05) CRANKCASE Parts Diagram

Chainsaw

CRANKCASE Parts Diagram

  • Title

1

Jonsered 530047963

ASSY-ISOLATOR
(Superseded to 545006036)

$13.99

$

In Stock, only 4 left!

0

2

Jonsered 530047608

STRAP
(Superseded to 530037009)

$

$

Not available

3

Jonsered 530042082

SPRING
(Superseded to 545006036)

$13.99

$

In Stock, only 4 left!

0

4

Jonsered 530015158

WASHER
(Superseded to 530015123)

$4.99

$

In Stock, only 4 left!

0

5

Jonsered 530016018

No Description Available

$

$

Not available

6

Jonsered 530015843

SCREW

$6.49

$

Usually ships in 3-10 days

0

7

Jonsered 530047583

HANDLE
(Superseded to 545048001)

$

$

Not available

8

Jonsered 530015940

SCREW

$6.49

$

In Stock, Qty 8

0

9

Jonsered 530015814

SCREW

$6.49

$

In Stock, Qty 16

0

12

Jonsered 530014381

SPIKE 36/41

$9.99

$

In Stock, Qty 8

0

13

Jonsered 530016439

SCREW

$6.49

$

Usually ships in 3-10 days

0

14

Jonsered 530016132

BOLT

$6.49

$

In Stock, Qty 10

0

15

Jonsered 530038238

PLATE

$

$

Not available

16

Jonsered 530015814

SCREW

$6.49

$

In Stock, Qty 16

0

17

Jonsered 530029850

CHAIN CATCHER 36/41

$6.49

$

In Stock, only 3 left!

0

18

Jonsered 530016133

BOLT

$6.49

$

In Stock, only 2 left!

0

19

Jonsered 530010846

OIL TANK CAP
(Superseded to 530057236)

$

$

Not available

20

Jonsered 530071666

KIT-OIL CHECK VALVE

$

$

Not available

21

Jonsered 530016134

NUT-FLYWHEEL

$6.49

$

In Stock, only 1 left!

0

22

Jonsered 530016080

SCREW

$6.49

$

In Stock, only 1 left!

0

23

Jonsered 530037817

STARTER PULLEY
(Superseded to 545034301)

$

$

Not available

24

Jonsered 530055723

AIR BAFFLE

$11.99

$

Usually ships in 3-10 days

0

25

Jonsered 530015892

SCREW,STRTR CVR 36/41

$6.49

$

In Stock, Qty 20+

0

26

Jonsered 530057099

No Description Available

$12.99

$

Usually ships in 3-10 days

0

27

Jonsered 530069232

KIT-ROPE

$7.49

$

In Stock, Qty 20+

0

28

Jonsered 530056402

HANDLE STARTER

$6.49

$

In Stock, only 1 left!

0

29

Jonsered 530027531

No Description Available
(Superseded to 545008015)

$7.99

$

In Stock, Qty 16

0

30

Jonsered 530015920

SCREW

$6.49

$

In Stock, Qty 7

0

31

Jonsered 530015127

WASHER-FLYWHEEL

$6.49

$

In Stock, only 2 left!

0

32

Jonsered 530039187

FLYWHEEL
(Superseded to 530047534)

$

$

Not available

33

Jonsered 530047192

TANK CAP
(Superseded to 580940901)

$7.99

$

In Stock, only 3 left!

0

34

Jonsered 530023877

FUEL LINE FITTING

$5.99

$

In Stock, Qty 18

0

35

Jonsered 530069216

LINE KIT

$11.99

$

In Stock, Qty 20+

0

38

Jonsered 530047581

HANDLE

$4.99

$

Usually ships in 3-10 days

0

39

Jonsered 530015886

SCREW-10-14 X 13/16 (PL

$6.49

$

In Stock, only 3 left!

0

40

Jonsered 530015906

SCREW,FRONT HBAR 36/41

$6.49

$

Usually ships in 3-10 days

0

41

Jonsered 530036098

THROTTLE LOCK

$

$

Not available

42

Jonsered 530036097

THROTTLE TRIGGER

$5.99

$

In Stock, only 3 left!

0

43

Jonsered 530047582

HANDLE

$15.99

$

Usually ships in 3-10 days

0

44

Jonsered 530015814

SCREW

$6.49

$

In Stock, Qty 16

0

45

Jonsered 530053274

SPRING
(Superseded to 545006036)

$13.99

$

In Stock, only 4 left!

0

46

Jonsered 530071385

SPRING
(Superseded to 545006036)

$13.99

$

In Stock, only 4 left!

0

47

Jonsered 530015875

SCREW

$4.99

$

In Stock, only 3 left!

0

48

Jonsered 530042082

SPRING
(Superseded to 545006036)

$13.99

$

In Stock, only 4 left!

0

51

Jonsered 530049005

GUIDE

$

$

Not available

52

Jonsered 530015922

CLIP

$6.49

$

In Stock, Qty 5

0

53

Jonsered 530058724

No Description Available

$

$

Not available

54

Jonsered 530015907

DUST COVER 36/41

$

$

Not available

55

Jonsered 530047061

CLUTCH DRUM ASSY

$17.99

$

In Stock, Qty 5

0

56

Jonsered 530015611

FRICTION DISC,CLUTCH 36/41

$6.49

$

In Stock, only 2 left!

0

57

Jonsered 530014949

CLUTCH ASSEMBLY

$22.99

$

In Stock, only 1 left!

0

58

Jonsered 530071259

OIL PUMP

$

$

Not available

59

Jonsered 530037820

WORM GEAR

$6.49

$

In Stock, only 3 left!

0

60

Jonsered 530049477

ELBOW

$4.99

$

In Stock, only 3 left!

0

61

Jonsered 530016064

SCREW

$4.99

$

In Stock, only 2 left!

0

62

Jonsered 530019206

SEALING

$6.49

$

Usually ships in 3-10 days

0

63

Jonsered 530047663

HOSE

$6.99

$

In Stock, Qty 5

0

64

Jonsered 530038373

PICK-UP OILER

$4.99

$

Usually ships in 3-10 days

0

65

Jonsered 530056533

SCREEN/FILTER

$6.49

$

In Stock, only 2 left!

0

66

Jonsered 530054678

No Description Available
(Superseded to 545139905)

$

$

Not available

67

Jonsered 530015917

BAR NUT

$3.99

$

In Stock, Qty 12

0

68

Jonsered 530015826

ADJUST PIN,BAR 36/41

$4.99

$

In Stock, Qty 20+

0

69

Jonsered 530038593

RETAINER

$4.99

$

In Stock, Qty 20+

0

70

Jonsered 530069611

RETAINER

$9.49

$

In Stock, Qty 13

0
