CRT 1350 LS (960930016-03) - Husqvarna Rear-Tine Tiller (2011-09) TINE SHIELD Parts Diagram

Rear-Tine Tiller

TINE SHIELD Parts Diagram

  • Title

1

Husqvarna 873900500

NUT LOCK HEX FLANGE 5/16-18
(Superseded to 583612701)

$

$

Not available

2

Husqvarna 532442966

SHIELD.SIDE.OUTER.LH.ORANGE

Note: LH

$24.99

$

Usually ships in 3-10 days

0

3

Husqvarna 532008393

STAKE PIN TI

$31.99

$

Usually ships in 3-10 days

0

4

Husqvarna 812000035

RING, KLIP

$7.49

$

In Stock, Qty 8

0

5

Husqvarna 532180847

BOLT, RDHD SQNK 5/16-18 X 3/4
(Superseded to 595901601)

$3.99

$

In Stock, Qty 20+

0

6

Husqvarna 532008394

SPRING TI

$9.49

$

In Stock, only 2 left!

0

7

Husqvarna 532008392

BRACKET.LATCH.STAKE.3.20.BLACK

$5.99

$

Usually ships in 3-10 days

0

8

Husqvarna 532109230

SPRING CRT

$6.49

$

In Stock, Qty 9

0

9

Husqvarna 532442961

SHIELD.TINE.TILLER.ORANGE

$91.99

$

Usually ships in 3-10 days

0

10

Husqvarna 872140508

BOLT

$2.99

$

Usually ships in 3-10 days

0

11

Husqvarna 873220500

NUT

$6.49

$

Usually ships in 3-10 days

0

12

Husqvarna 810040500

LOCKWASHER
(Superseded to 596238801)

$3.99

$

In Stock, only 4 left!

0

14

Husqvarna 532124343

BRACKET.TINE.SHIELD.TILLER
(Superseded to 584459301)

$37.99

$

Usually ships in 3-10 days

0

15

Husqvarna 532442965

SHIELD.SIDE.OUTER.RH.ORANGE

Note: RH

$24.99

$

Usually ships in 3-10 days

0

16

Husqvarna 873900400

NUT T
(Superseded to 873680400)

$4.99

$

In Stock, Qty 20+

0

18

Husqvarna 872040410

BOLT

$6.49

$

Usually ships in 3-10 days

0

19

Husqvarna 532102701

GRIP CRT

$

$

Not available

20

Husqvarna 873220600

NUT.HEX.3/8-16UNC

$6.49

$

In Stock, only 2 left!

0

21

Husqvarna 532138420

STAKE.ASM.DEPTH

$56.99

$

Usually ships in 3-10 days

0

22

Husqvarna 874930632

BOLT.375-16

$6.99

$

In Stock, only 2 left!

0

23

Husqvarna 532004440

HINGE CRT

$6.49

$

In Stock, only 1 left!

0

24

Husqvarna 872140404

BOLT

$6.49

$

Usually ships in 3-10 days

0

25

Husqvarna 532124717

VINYL CAP TI
(Superseded to 532006712)

$6.49

$

Usually ships in 3-10 days

0

26

Husqvarna 532109227

PAD IDLER TI

$4.99

$

In Stock, Qty 20+

0

27

Husqvarna 532442990

SHIELD.PNT.LEVELING.ORANGE.668

$54.99

$

Usually ships in 3-10 days

0

28

Husqvarna 532138609

PIN, HINGE

$6.49

$

Usually ships in 3-10 days

0

29

Husqvarna 532442967

SHIELD.ASM.PNT.SIDE.ORANGE.668

$27.99

$

Usually ships in 3-10 days

0

30

Husqvarna 873970500

LOCKNUT-FLANGE 5/16-18
(Superseded to 873680500)

$3.99

$

Usually ships in 3-10 days

0

32

Husqvarna 873220400

NUT
(Superseded to 532050675)

$6.49

$

In Stock, only 1 left!

0

33

Husqvarna 810040400

LOCKWASHER
(Superseded to 596029801)

$3.99

$

In Stock, only 2 left!

0

34

Husqvarna 874490536

BOLT

$

$

Not available

38

Husqvarna 873510500

NUT
(Superseded to 873680500)

$3.99

$

Usually ships in 3-10 days

0
