Comfort Control DD (5900992) - Ferris Comfort Control DD 52" Walk-Behind Mower, 26hp Kawasaki, Rear-Discharge 48" & 52" Mower Deck - Housing, Covers, Spindles & Blades (Rear Discharge) Parts Diagram

Comfort Control DD 52" Walk-Behind Mower, 26hp Kawasaki, Rear-Discharge

48" & 52" Mower Deck - Housing, Covers, Spindles & Blades (Rear Discharge) Parts Diagram

  • Title

1A

Ferris 5600227

DECK SHELL W/DECALS

Note: (48" Models)

$1709.99

$

Usually ships in 2-12 days

0

1B

Ferris 5600225

DECK SHELL W/DECALS

Note: (52" Models)

$1880.99

$

Usually ships in 2-12 days

0

2

Ferris 5025320X14

BOLT, 5/8-11 X 1-3/4 GD8
(Superseded to 5025320X14FS)

$3.49

$

Usually ships in 2-12 days

0

3

Ferris 5025477

WASHER, 5/8 GRADE 8, YZ
(Superseded to 5025477SM)

$3.99

$

In Stock, Qty 11

0

4A

Ferris 5020843S

BLADE SET, 48 DECK (SET OF 3 BLADES)

Note: (48" Models)

$

$

Currently unavailable

4B

Ferris 5021227S

BLADE, 18 (3) SET

Note: (52" Models)

$80.99

$

Usually ships in 2-12 days

0

5

Ferris 5025392

NUT, 5/16-18 HEX NYLOCK FLANGE
(Superseded to 5025392FS)

$3.49

$

Usually ships in 2-12 days

0

6

Ferris 5023156

BOLT, 5/16-18 X 1 1/4 FLANGE
(Superseded to 5023156SM)

$3.99

$

In Stock, only 1 left!

0

7

Ferris 5061095

ASSM, SPINDLE, LOW PROFILE
(Superseded to 5061095FS)

Note: (Nut and Washer Sold Seperately)

$231.99

$

Usually ships in 2-12 days

0

8A

Ferris 5402627B

BAFFLE, FRONT DISCHARGE, LH

Note: (48" Models)

$41.99

$

Usually ships in 2-12 days

0

8B

Ferris 5402629B

BAFFLE, FRONT DISCHARGE, LH

Note: (52" Models)

$44.99

$

Usually ships in 2-12 days

0

9A

Ferris 5402628B

BAFFLE, FRONT DISCHARGE, RH

Note: (48" Models)

$41.99

$

Usually ships in 2-12 days

0

9B

Ferris 5402630B

BAFFLE, FRONT DISCHARGE, RH

Note: (52" Models)

$44.99

$

Usually ships in 2-12 days

0

10

Ferris 5025155

WASHER, 5/16" SAE

$

$

Currently unavailable

11A

Ferris 5402327B

GUARD, DECK, LH

Note: (48" Models)

$16.99

$

Usually ships in 2-12 days

0

11B

Ferris 5402249B

GUARD, DECK, LH

Note: (52" Models)

$25.99

$

Usually ships in 2-12 days

0

12

Ferris 5402328B

GUARD, DECK, RH

$17.99

$

Usually ships in 2-12 days

0

13

Ferris 5025011X8

BOLT, 5/16-18 X 1 GD5 YZ
(Superseded to 5025011X8FS)

$3.49

$

In Stock, Qty 16

0

14

Ferris 5022308

BODY CLIP, 5/16-18-7GA MATERIAL
(Superseded to 5022308SM)

$5.99

$

In Stock, only 2 left!

0

15

Ferris 5101352

SPACER, .33 X .50 X .75
(Superseded to 5101352FS)

Note: (48" Models)

$6.99

$

Usually ships in 2-12 days

0

16A

Ferris 5025011X12

BOLT, 5/16-18 X 1-1/2 GD5 YZ
(Superseded to 5025011X12SM)

Note: (48" Models)

$3.99

$

In Stock, only 2 left!

0

16B

Ferris 5025011X8

BOLT, 5/16-18 X 3/4 GD5
(Superseded to 5025011X8FS)

$3.49

$

In Stock, Qty 16

0

17A

Ferris 5408909B

WELD, REAR BAFFLE
(Superseded to 5408909BFS)

Note: (48" Models - S/N: 2015620609 & Above)

$240.99

$

Usually ships in 2-12 days

0

17B

Ferris 5408916B

WELD, REAR BAFFLE

Note: (52" Models - S/N: 2015620609 & Above)

$

$

Currently unavailable

18

Ferris 5025145X10

BOLT, 5/16-18 X 1-1/4, CARRIAGE YZ
(Superseded to 5025145X10YP)

$3.49

$

Usually ships in 2-12 days

0
