CHF 9540 H - Bear Cat 9" Chipper, 540cc PTO Hydraulic Feed, Fine Chip (SN: D00001 - G08143) Drive Assembly - Rear (SN: G04608 - G08143) Parts Diagram

8" Chipper, 540cc PTO Hydraulic Feed, Fine Chip

Drive Assembly - Rear (SN: G04608 - G08143) Parts Diagram

  • Title
1

0111-0058-00

RIVET, 1/4 X 3/4 ST POP

$

$

Not available

2

Bear Cat 14544-00

PIN, HITCH 1/2 X 6-1/2 W LYNCH

$37.99

$

Usually ships in 3-7 days

0

3

Bear Cat 15015

BOLT, 1/2 X 2 GR5 HEX CAPSCREW ZP

$

$

Not available

4

Bear Cat 15034

WASHER, 1/2" FLAT ZP

$

$

Not available

5

Bear Cat 15043

NUT, 1/2" HEX NC ZP

$

$

Not available

6

Bear Cat 15049

NUT, 1/2" CENTERLOCK GRB ZP

$

$

Not available

7

15079-00

BOLT, 1/4-20 X 3/4 HWH GR5 CZP

$

$

Not available

8

Bear Cat 15116

BOLT, 3/8 X 2-1/2 GR5 HHCS ZP

$

$

Not available

9

Bear Cat 15388

NUT, 3/8" NE NYLOCK ZP

$

$

Not available

10

Bear Cat 15481

STUD, 1/2"-13 X 3" LG B7 ZP

$17.99

$

Usually ships in 3-7 days

0

11

15855-00

BOLT, 1/2 X 1-1/2 GR8 NC ZP HEX HD

$

$

Not available

12

Bear Cat 15900-00

NUT, 1/4-20 NYLOCK-FLANGE

$0.99

$

Usually ships in 3-7 days

0

13

Bear Cat 16460

CAP, LARGE SHAFT

$

$

Not available

14

Bear Cat 16553

BEARING, 1-3/4 4 BOLT FLANGE

$

$

Not available

15

Bear Cat 18549-00

CLAMP, CABLE MOUNT

$7.99

$

Usually ships in 3-7 days

0

16

Bear Cat 71050-12

WELDMENT, BLOCK ADJUSTOR

$

$

Not available

Bear Cat 71118-00

ASSEMBLY, 9" CHIPPER ROTOR

Note: (INCLUDES 3, 6 & 17-21)

$4567.99

$

Usually ships in 3-7 days

0

17

Bear Cat 15770-00

WASHER, 5/8 SAE HARDENED

$2.49

$

Usually ships in 3-7 days

0

18

Bear Cat 15833-00

BOLT, M16 X 2.0 X 30 HEX HD W/PATCH

$11.99

$

Usually ships in 3-7 days

0

19

Bear Cat 71541-00

KIT, BIG CHIPPER FORMED PADDLES

Note: (INCLUDES ITEMS 3, 6 &19)

$336.99

$

Usually ships in 3-7 days

0

20

Bear Cat 76287-00

ASSEMBLY, 9 INCH CHIPPER ROTOR

$3871.99

$

Usually ships in 3-7 days

0

21

Bear Cat 76293-00

KIT, CHIPPER BLADE
(Superseded to 78361-00)

Note: (INCLUDES ITEMS 17, 18 & 21)

$481.99

$

In Stock, only 1 left!

0

22

Bear Cat 71132-12

PLATE, CHIPPER BOTTOM

$

$

Not available

23

Bear Cat 71280

COLLAR, CHIPPER LOCK

$

$

Not available

24

Bear Cat 75960-12

BRACKET, ROTOR LOCK

$

$

Not available

17320

STRAP, 11 IN BLACK TIE

Note: (NOT SHOWN)

$

$

Not available
