Challenger 700 Yellow (37AX7CKD010) - Cub Cadet 4x4 Utility Vehicle Steering wheel parts Parts Diagram

4x4 Utility Vehicle

Steering wheel parts Parts Diagram

  • Title

1

Cub Cadet 62600-115N-0000

Steering Mechanism Comp
(Superseded to 503-00365)

$490.99

$

Usually ships in 3-6 days

0

2

Cub Cadet 62621-115-0000

Driving Gear

$82.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 63400-115-0000

Steering Wheel Comp
(Superseded to 503-00363)

$202.99

$

Usually ships in 3-6 days

0

4

Cub Cadet B01-8-B7

Spring Washer -8
(Superseded to 503-00005)

$6.49

$

In Stock, only 4 left!

0

5

Cub Cadet 63424-115-0000

Upper Cover, Steering Wheel

$8.49

$

Usually ships in 3-6 days

0

6

Cub Cadet 63422-115-0000

Middle Cover, Steering Wheel
(Superseded to 503-00360)

$25.99

$

Usually ships in 3-6 days

0

7

Cub Cadet 63405-115-0000

Socket Hexagon Screw M6x16
(Superseded to 503-00376)

$5.49

$

Usually ships in 3-6 days

0

8

Cub Cadet 90752-115-0005

Pipe Clamp 15

$3.99

$

Usually ships in 3-6 days

0

9

Cub Cadet 63423-115-0000

Decoration Cover, Steering Wheel
(Superseded to 503-00359)

$31.99

$

Usually ships in 3-6 days

0

10

Cub Cadet 62627-115-0000

Clip
(Superseded to 503-00387)

$18.99

$

Usually ships in 3-6 days

0

11

Cub Cadet 62626-115-0000

Rubber Dust Cover

$16.99

$

Usually ships in 3-6 days

0

12

Cub Cadet B06-M10X1.25X35

Hexagon Flange Bolt M10x1.25x35

$2.49

$

Usually ships in 3-6 days

0

13

Cub Cadet 62610-119-0000

Steering Wheel Ball Joint

$41.99

$

Usually ships in 3-6 days

0

14

Cub Cadet B08-M14-22

Nut M14

$

$

Not available

15

Cub Cadet 62700-115-0000

Steering Drive Axle
(Superseded to 503-00364)

$192.99

$

Usually ships in 3-6 days

0

16

Cub Cadet B05-M8X25-57

Hexagon Flange Bolt M8x25
(Superseded to 90183-115-0002)

$8.49

$

Usually ships in 3-6 days

0

17

Cub Cadet 62130-115-0100

Steering Column

$48.99

$

Usually ships in 3-6 days

0

18

Cub Cadet B05-M8X25-57

Hexagon Flange Bolt M8x25
(Superseded to 90183-115-0002)

$8.49

$

Usually ships in 3-6 days

0

19

Cub Cadet B11-M14X1.5-27

Nut M14x1.5

$2.49

$

Usually ships in 3-6 days

0

20

Cub Cadet B12-2X32-W7

Cotter pin 2x32
(Superseded to B12-2X30-W7)

$2.49

$

Usually ships in 3-6 days

0

21

Cub Cadet N/A

Steering Wheel Body

Note: (refer to ref. no. 3)

$

$

Currently unavailable

22

Cub Cadet B22-M5-27

Hexagon flange nut M5
(Superseded to 503-00374)

$5.49

$

Usually ships in 3-6 days

0

23

Cub Cadet 90542-102-0007

Cross Large Plate Head Screw M5x12

$2.49

$

In Stock, only 2 left!

0

24

Cub Cadet 37200-120E-0100

Ignition switch
(Superseded to 503-00362)

$125.99

$

Usually ships in 3-6 days

0

24

Cub Cadet 37225-115-1100

Key Blanks

Note: (not shown) (2 blank keys)

$8.49

$

In Stock, only 2 left!

0

25

Cub Cadet B10-M12X1.25-27

Hexagon Flange Nut M12x1.25

$2.49

$

Usually ships in 3-6 days

0

26

Cub Cadet B01-5-B7

Washer 5

$2.49

$

Usually ships in 3-6 days

0

27

Cub Cadet 90404-103-0000

Tapping Clamp F4.2
(Superseded to 503-00369)

$3.49

$

Usually ships in 3-6 days

0

28

Cub Cadet 37272-115-0000

Screw M5x16
(Superseded to 90691-102-0003)

$4.99

$

Usually ships in 3-6 days

0

29

Cub Cadet 37530-115N-0000

Combination Switch
(Superseded to 503-00361)

$141.99

$

Usually ships in 3-6 days

0

30

Cub Cadet 90542-102-0001

Cross Large Plate Head Screw M5x16
(Superseded to 503-00142)

$4.49

$

In Stock, only 2 left!

0

31

Cub Cadet B18ST4.8X16C-W7

Bolt 4.8x16

$2.49

$

In Stock, only 4 left!

0

32

Cub Cadet 62112-115-0000

Upper Cover,Ignition Switch
(Superseded to 503-00367)

$11.99

$

Usually ships in 3-6 days

0

33

Cub Cadet 62113-116-0000

Lower Cover,Ignition Switch
(Superseded to 503-00368)

$34.99

$

Usually ships in 3-6 days

0

34

Cub Cadet 90404-103-0000

Tapping Clamp F4.2
(Superseded to 503-00369)

$3.49

$

Usually ships in 3-6 days

0

35

Cub Cadet B03-5-B7

Washer 5x15x1.2

$2.49

$

In Stock, only 4 left!

0

36

Cub Cadet 63426-115-0000

Decoration Cover, Steering Column

$17.99

$

Usually ships in 3-6 days

0

37

Cub Cadet 94027-115-0000

Rubber Cushion, Ignition Switch Cover

$5.49

$

Usually ships in 3-6 days

0

38

Cub Cadet 63425-115-0000

Lower Cover, Steering Wheel

$10.99

$

Usually ships in 3-6 days

0

39

Cub Cadet 90691-112-0005

Cushion 15x28x2

$5.49

$

Usually ships in 3-6 days

0

40

Cub Cadet B01-14-B7

Spring Washer -14

$2.49

$

Usually ships in 3-6 days

0

41

Cub Cadet B04-8.4-B7

Cushion 8.4x16x1.6
(Superseded to 503-00167)

$4.99

$

Usually ships in 3-6 days

0

42

Cub Cadet B04-10-B7

Washer10x20x2
(Superseded to 503-00058)

$5.49

$

In Stock, only 4 left!

0

43

Cub Cadet B01-10-B7

Spring washer -10
(Superseded to 503-00064)

$6.49

$

In Stock, only 3 left!

0
