Challenger 400 Yellow (37BV3BHK010) - Cub Cadet 4x4 Utility Vehicle (2018) Control Parts Diagram

4x4 Utility Vehicle

Control Parts Diagram

  • Title

1

Cub Cadet 907-05191

SHIFT CONTROL ASSEMBLY

Note: (See Separate Breakdown)

$191.99

$

In Stock, only 1 left!

0

2

Cub Cadet 607-05200

BRAKE PEDAL ASSEMBLY

Note: *CHOOSE COLOR WHEN ORDERING*

Variations

Cub Cadet 607-05200-0637

BLACK BRAKE PEDAL ASS - POWDER BLACK (0637)

$72.99

$

Usually ships in 3-6 days

0

$72.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 607E05268

SHIFT BRACKET WELD ASSEMBLY

$56.99

$

Usually ships in 3-6 days

0

4

Cub Cadet 607-05287

GAS PEDAL ASSEMBLY

Note: *CHOOSE COLOR WHEN ORDERING*

Variations

Cub Cadet 607-05287-0637

BLACK GAS PEDAL ASSEM - POWDER BLACK (0637)

$72.99

$

Usually ships in 3-6 days

0

$72.99

$

Usually ships in 3-6 days

0

5

Cub Cadet 661-04042

MASTER CYLINDER ASSEMBLY

$183.99

$

Usually ships in 3-6 days

0

6

Cub Cadet 707-06854

PEDAL MOUNTING BRACKET

Note: *CHOOSE COLOR WHEN ORDERING*

Variations

Cub Cadet 707-06854-0637

BLACK PEDAL MOUNTING - POWDER BLACK (0637)

$20.99

$

Usually ships in 3-6 days

0

$20.99

$

Usually ships in 3-6 days

0

7

Cub Cadet 707-06923

THROTTLE BRACKET

$18.99

$

Usually ships in 3-6 days

0

8

Cub Cadet 710-04484

SCREW 5/16-18 x .750

$3.99

$

In Stock, Qty 20+

0

9

Cub Cadet 710-04532

CARRIAGE BOLT 5/16-18 x 2.00 GR5

$6.49

$

In Stock, Qty 5

0

10

Cub Cadet 710-05074

SCREW 1/4-20 x 1.0

$3.49

$

Usually ships in 3-6 days

0

11

Cub Cadet 710-0599

SCREW 1/4-20 X.500

$4.49

$

In Stock, Qty 20+

0

12

Cub Cadet 710-06085

SCREW M5-.8X10MM SLOT/TORX

$3.49

$

Usually ships in 3-6 days

0

13

Cub Cadet 710-06133

SCREW M6-1 x .625

$3.99

$

In Stock, Qty 15

0

14

Cub Cadet 710-0642

SCREW 1/4-20 x .750

$4.49

$

In Stock, Qty 20+

0

15

Cub Cadet 710-3056

SCREW 5/16-18 x 3.25 GR5

$10.99

$

In Stock, only 1 left!

0

16

Cub Cadet 710-3103

SCREW 5/16-18 x 2.0 GR5

$4.49

$

In Stock, only 4 left!

0

17

Cub Cadet 711-0653

CLEVIS PIN .312 x 1.0

$3.99

$

Usually ships in 3-6 days

0

18

Cub Cadet 712-04063

FLANGE LOCK NUT 5/16-18

$3.99

$

In Stock, Qty 20+

0

19

Cub Cadet 712-04065

NUT

$3.99

$

In Stock, Qty 20+

0

20

NUT

Note: (Comes with Ref.43)

$

$

Not available

21

Cub Cadet 912-3010

HEX NUT
(Superseded to 712-3010)

$4.49

$

In Stock, Qty 20+

0

22

Cub Cadet 712-3025

HEX JAM NUT 5/16-24 GR 5

$7.49

$

Usually ships in 3-6 days

0

23

Cub Cadet 712-3086

HEX FLANGE NUT M8X

$4.49

$

In Stock, only 2 left!

0

24

Cub Cadet 714-04040

BOW TIE COTTER PIN 1/4-5/16

$1.49

$

In Stock, Qty 20+

0

25

Cub Cadet 719-3018

ADJUSTABLE ROD END

$43.99

$

Usually ships in 3-6 days

0

26

Cub Cadet 720-05107

GRIP

$14.99

$

Usually ships in 3-6 days

0

27

Cub Cadet 725-04507

BRAKE SWITCH

$137.99

$

Usually ships in 3-6 days

0

28

Cub Cadet 726-0273

MOUNTING CLAMP

$7.49

$

In Stock, only 1 left!

0

29

Cub Cadet 726-0317

TIE CABLE 8.5 LG

$4.99

$

Usually ships in 3-6 days

0

30

Cub Cadet 726-0470

CABLE TIE

$4.99

$

Usually ships in 3-6 days

0

31

Cub Cadet 727-05159

BRAKE HOSE (FRONT MASTER CYLINDER)

$61.99

$

Usually ships in 3-6 days

0

32

Cub Cadet 727-05160

BRAKE HOSE (FRONT)

$70.99

$

Usually ships in 3-6 days

0

33

Cub Cadet 727-05161

BRAKE HOSE (LEFT HAND REAR)

$70.99

$

Usually ships in 3-6 days

0

34

Cub Cadet 727-05162

BRAKE HOSE (RIGHT HAND REAR)

$70.99

$

Usually ships in 3-6 days

0

35

Cub Cadet 727-05164

BRAKE HOSE (REAR MASTER CYLINDER)

$100.99

$

Usually ships in 3-6 days

0

36

Cub Cadet 731-04735

BRAKE HANDLE GRIP

$20.99

$

In Stock, only 1 left!

0

37

Cub Cadet 732-05582

TORSION SPRING

$8.49

$

Usually ships in 3-6 days

0

38

Cub Cadet 737-04128

TEE FITTING

$57.99

$

Usually ships in 3-6 days

0

39

Cub Cadet 737-04129

BANJO FITTING

$28.99

$

Usually ships in 3-6 days

0

40

Cub Cadet 737-04130

BANJO FITTING

$8.99

$

Usually ships in 3-6 days

0

41

Cub Cadet 938-3056

SHOULDER BOLT

$9.49

$

In Stock, Qty 20+

0

42

Cub Cadet 741-0491

NYLINER BEARING

$5.49

$

In Stock, only 4 left!

0

43

Cub Cadet 946-05372

CHOKE CABLE 93"

$64.99

$

Usually ships in 3-6 days

0

44

Cub Cadet 946-05406

SHIFT CABLE 44"

$114.99

$

Usually ships in 3-6 days

0

45

Cub Cadet 946-05442

THROTTLE CONTROL CABLE 108"

$94.99

$

Usually ships in 3-6 days

0

46

Cub Cadet 747-06999

CABLE GUIDE ROD

$8.49

$

Usually ships in 3-6 days

0

47

Cub Cadet 750-06574

SPACER

$5.49

$

Usually ships in 3-6 days

0
