CH 5540 H - Bear Cat 5" Chipper, 540cc PTO Driven (SN: D00001 - G05696) Switch Box CE COMPLIANT (SN: F03872 - G05696) Parts Diagram

5" Chipper, 540cc PTO Driven

Switch Box CE COMPLIANT (SN: F03872 - G05696) Parts Diagram

  • Title

1

Bear Cat 12620

SPRING, CONTROL BAR

$24.99

$

Usually ships in 3-7 days

0

2

Bear Cat 12621

WASHER, UHMW SPACER .515ID-1.50OD

$9.49

$

Usually ships in 3-7 days

0

3

Bear Cat 13717-00

SWITCH, FEED CONTROL

$105.99

$

Usually ships in 3-7 days

0

4

Bear Cat 15097

WASHER, 1/2" SAE FLAT ZP

$

$

Not available

5

Bear Cat 15250

WASHER, 5/16" FLAT ZP

$

$

Not available

6

15344

BOLT, 1/4 X 1/2" SERRATED FLANGE GR5 ZP

$

$

Not available

7

Bear Cat 15904-00

NUT, 5/16-18 NYLOCK-FLANGE

$

$

Not available

8

Bear Cat 18555-00

DECAL, RESET/OVERRIDE

$37.99

$

Usually ships in 3-7 days

0

9

Bear Cat 30334-00

LIGHT, LED TRI-COLOR

$64.99

$

Usually ships in 3-7 days

0

10

Bear Cat 32376-00

SWITCH, MOMENTARY IP65 NORMALLY OFF

$47.99

$

Usually ships in 3-7 days

0

11

70024-00

ASSEMBLY, 5" CONTROL COVER W/ DECAL, SERVICE PART

Note: (INCLUDES ITEM 12)

$

$

Not available

12

Bear Cat 14942-00

DECAL, MULTILINGUAL MANUAL

$3.49

$

Usually ships in 3-7 days

0

13

71422-12

WELDMENT, XE CONTROL BOX

$

$

Not available

14

Bear Cat 73064

SPACER, .50 X .775

$16.99

$

Usually ships in 3-7 days

0

15

Bear Cat 73287-12

BAR, SWITCH CONTROL

$

$

Not available
