CH 45540 - Bear Cat 4.5" Chipper, 540cc PTO Driven (SN: D00001 & Above) Rotor, Blades & Bearings (SN: D00001 - E00821) Parts Diagram

4.5" Chipper, 540cc PTO Driven

Rotor, Blades & Bearings (SN: D00001 - E00821) Parts Diagram

  • Title
1

Bear Cat 12145

SHEAVE, 2B4.8 SDS

$114.99

$

Usually ships in 3-7 days

0

2

Bear Cat 14768-00

SNAP RING, 1-1/4 EXT. HEAVY DUTY

$7.49

$

Usually ships in 3-7 days

0

3

Bear Cat 14769-00

BUSHING, SDS 1-1/4"

$67.99

$

Usually ships in 3-7 days

0

4

Bear Cat 15014

BOLT, 1/2 X 1-1/2 HEX HD GR5 ZP

$1.49

$

In Stock, only 3 left!

0

5

Bear Cat 15049

NUT, 1/2 CENTERLOCK GRB ZP

$

$

Not available

6

Bear Cat 15097

WASHER, 1/2 SAE FLAT ZP

$

$

Not available

7

Bear Cat 15157

BOLT, 1/2 X 1-1/2 CRG GR5 ZP

$8.49

$

Usually ships in 3-7 days

0

8

Bear Cat 15250

WASHER, 5/16 FLAT ZP

$

$

Not available

9

15300

BOLT, 5/16 X 5/8 HEX HD GR5 ZP

$

$

Not available

10

Bear Cat 15356

NUT, 5/16 NE NYLOCK ZP

$

$

Not available

11

Bear Cat 15391

KEY, 1/4 SQUARE X 2 LONG PLAIN

$

$

Not available

12

Bear Cat 15770-00

WASHER, 5/8 SAE HARDENED

$2.49

$

Usually ships in 3-7 days

0

13

Bear Cat 15833-00

BOLT, M16 X 2.0 X 30 HEX HD W/PATCH

$11.99

$

Usually ships in 3-7 days

0

14

Bear Cat 16682

BEARING, 1-1/4" DIA 2 BOLT FLANGE

$

$

Not available

15

Bear Cat 17913

DECAL, ECHO BEARCAT 6.82 X 1.90

$6.49

$

Usually ships in 3-7 days

0

16

Bear Cat 18061-00

DECAL, ROTATING SHAFT

$11.99

$

Usually ships in 3-7 days

0

17

Bear Cat 74529-00

ANVIL, CHIPPER

$54.99

$

Usually ships in 3-7 days

0

18

WELDMENT, DISK COVER (REPLACED AND SUPERSEDED 77721-35. FOR SERVICE ORDER PN 70026-00)

$

$

Not available

19

SHIM, BEARING (WAS 75550-00, REMOVED)

$

$

Not available

20

Bear Cat 76295-00

BLADE, BIG CHIPPER (FOR SERVICE ORDER REPLACEMENT BLADE KIT 76295-00)

$

$

Not available

20

Bear Cat 32839-00

KIT, 4-1/2 CHIPPER BLADE KIT
(Superseded to 77798-00)

$995.99

$

Usually ships in 3-7 days

0

21

WELDMENT, 4-1/2 PTO DISK

$

$

Not available
