CB 65 (59A40005727) - Cub Cadet Yanmar Tractor 7.5' Curved Boom Backhoe Attachment Swing System & Stabilizer Area Parts Diagram

Tractor 7.5' Curved Boom Backhoe Attachment

Swing System & Stabilizer Area Parts Diagram

  • Title

1

Cub Cadet AQ-000187

HYDRAULIC CYLINDER, SWING

$

$

Not available

5

Cub Cadet AQ-000242

HYDRAULIC CYLINDER, STABILIZER

$

$

Not available

7

Cub Cadet AQ-006577

CARRIAGE BOLT, 5/16-18 X 1.00 GR 5

$

$

Not available

8

Cub Cadet AQ-006669

CARRIAGE BOLT, 1/2-13 X 1.75 GR 2

$

$

Not available

10

Cub Cadet AQ-006758

HEX HEAD CAP SCREW, 1/4-20 X 1.750 GR 5

$

$

Not available

11

Cub Cadet AQ-006759

HEX HEAD CAP SCREW, 1/4-20 X 2.0

$

$

Not available

13

Cub Cadet AQ-006787

HEX HEAD CAP SCREW, 5/16-18 X .75 GR 5

$

$

Not available

19

Cub Cadet AQ-006808

HEX HEAD CAP SCREW 5/16-24 X 2.250 GR 5

$

$

Not available

21

Cub Cadet AQ-006818

HEX HEAD CAP SCREW, 5/16-18 X 3.0 GR 5

$

$

Not available

24

Cub Cadet AQ-007012

HEX HEAD CAP SCREW, 1/2-20 X 1.0 GR 5 SAE

$

$

Not available

25

Cub Cadet AQ-007088

HEX HEAD CAP SCREW, 1/2-20 X 6.50 GR 5

$

$

Not available

27

Cub Cadet AQ-007403

NUT, HEX 1/4-20 GR 5 LOCK

$

$

Not available

28

Cub Cadet AQ-007431

NUT, HEX 5/16-18 GR 5

$

$

Not available

29

Cub Cadet AQ-007433

NUT, HEX 5/16-18 GR 5 LOCK

$

$

Not available

30

Cub Cadet AQ-007437

NUT, HEX 5/16-24 LOCK

$

$

Not available

32

Cub Cadet AQ-007501

NUT, HEX 1/2-13 GR 5

$

$

Not available

33

Cub Cadet AQ-007515

NUT, HEX 1/2-20 GR 5 LOCK

$

$

Not available

35

Cub Cadet AQ-008071

LOCK WASHER, 5/16

$

$

Not available

36

Cub Cadet AQ-008101

LOCK WASHER, 1/2

$

$

Not available

37

Cub Cadet AQ-008146

FLAT WASHER, 1/4 SAE

$

$

Not available

38

Cub Cadet AQ-008151

FLAT WASHER, 5/16

$

$

Not available

39

Cub Cadet AQ-008152

FLAT WASHER, 5/16 SAE

$

$

Not available

41

Cub Cadet AQ-008272

MACHINE BUSHING, 1-1/4 X 3/4 X 14GA

$

$

Not available

43

Cub Cadet AQ-008304

MACHINE BUSHING, 2-1/2 X 1-3/4 X 14GA

$

$

Not available

44

Cub Cadet AQ-008582

COTTER PIN, HARD 3/16 X 1.25

$

$

Not available

45

Cub Cadet AQ-008602

COTTER PIN, 1/4 X 1-1/2

$

$

Not available

55

Cub Cadet AQ-011978

PRE LUBRICATED BEARING

$

$

Not available

57

Cub Cadet AQ-012907

STEP PAD SURFACING 3X3

$

$

Not available

58

Cub Cadet AQ-012910

STEP PAD SURFACING 5X6

$

$

Not available

61

Cub Cadet AQ-013491

LINCH PIN

$

$

Not available

63

Cub Cadet AQ-013505

FASPIN, 3/4 DIA X 3

$

$

Not available

64

Cub Cadet AQ-013679

RUBBER BUMPER

$

$

Not available

67

Cub Cadet AQ-013857

SEAT, BACKHOE

$

$

Not available

76

Cub Cadet AQ-014172

CABLE ASSEMBLY

$

$

Not available

80

Cub Cadet AQ-014505

GREASE FITTING, 1/4-28, STRT

$

$

Not available

81

Cub Cadet AQ-014521

GREASE FITTING, 1/4-28, 45 DEG

$

$

Not available

99

Cub Cadet AQ-849119

SPACER, LONG

$

$

Not available

101

Cub Cadet AQ-851136

THRUST WASHER

$

$

Not available

105

Cub Cadet AQ-860450

PIVOT PIN WELDMENT

$

$

Not available

106

Cub Cadet AQ-860456

PIVOT PIN, 3/4" DIA X 4-1/16

$

$

Not available

107

Cub Cadet AQ-860459

PIVOT PIN, 3/4" DIA X 5-5/8

$

$

Not available

108

Cub Cadet AQ-860460

SWING CYL PIN WELDMENT

$

$

Not available

109

Cub Cadet AQ-860466

PIVOT PIN, STAB PAD

$

$

Not available

110

Cub Cadet AQ-860467

PIVOT PIN, STAB CYL ROD

$

$

Not available

111

Cub Cadet AQ-861675

UPPER PIVOT PIN WELDMENT

$

$

Not available

113

Cub Cadet AQ-861720

SEAT BRACKET WELDMENT

$

$

Not available

121

Cub Cadet AQ-865500

MAINFRAME WELDMENT

$

$

Not available

123

Cub Cadet AQ-865520

RH FLOOR WELDMENT

$

$

Not available

124

Cub Cadet AQ-865525

LH FLOOR WELDMENT

$

$

Not available

125

Cub Cadet AQ-865530

STEP WELDMENT

$

$

Not available

127

Cub Cadet AQ-868135

STABILIZER LEG WELDMENT

$

$

Not available

128

Cub Cadet AQ-868140

STABILIZER PAD WELDMENT

$

$

Not available

129

Cub Cadet AQ-M88183

RING LOCKING

$

$

Not available

130

Cub Cadet AQ-866165

SEAT PLATE WELDMENT

$

$

Not available
