BM 801700 (090079274) - Black Max 3000 PSI Pressure Washer Figure B Parts Diagram

3000 PSI Pressure Washer

Figure B Parts Diagram

  • Title

1

Homelite 522032011

Top Motor Housing

$

$

Not available

2

Homelite 760504007

Switch

$10.99

$

In Stock, only 1 left!

0

3

Homelite 870601001

Wire Nut

$

$

Not available

4

Homelite 570740016

Switch Cover Gasket

$

$

Not available

5

Homelite 561383012

Grommet

$

$

Not available

6

Homelite 561383024

Grommet

$

$

Not available

7

Homelite 570417002

Switch Cover

$

$

Not available

8

Homelite 661403015

Screw (M3 x 14 mm)

$

$

Not available

9

Homelite 661403016

Screw (M4 x 15 mm)

$1.99

$

Usually ships in 3-7 days

0

10

Homelite 522038012

Pump Cover

$

$

Not available

11

Homelite 310870002

Pressure Switch

$27.99

$

In Stock, only 1 left!

0

12

Homelite 678799014

U-clip

$

$

Not available

13

Homelite 570742071

O-ring
(Superseded to 570742086)

$

$

Not available

14

Homelite 638397003

Brass Washer

$1.99

$

In Stock, only 1 left!

0

15

Homelite 570570002

Bushing

$

$

Not available

16

Homelite 308833014

Motor/Pump Assembly
(Superseded to 308833019)

$

$

Not available

17

Homelite 980414010

Foam

$

$

Not available

18

Homelite 525894001

Lower Gasket

$1.99

$

Usually ships in 3-7 days

0

19

Homelite 522038011

Lower Motor Housing

$

$

Not available

20

Homelite 522051003

Cord Clamp

$1.99

$

Usually ships in 3-7 days

0

21

Homelite 661610008

Screw (M35 x 20 mm)

$

$

Not available

22

Homelite 290426019

Power Cord

$

$

Not available

23

Homelite 561383025

Grommet

$

$

Not available

24

Homelite 940603006

Cord Plug Label

$

$

Not available

25

Homelite 940324013

Cord Wrap Warning Label

$2.49

$

Usually ships in 3-7 days

0
