Big Country 640 (37AS640B100) - Cub Cadet 6x4 Utility Vehicle (SN: 1D302B & Before) Bed Lift Parts Diagram

6x4 Utility Vehicle

Bed Lift Parts Diagram

  • Title

1

Cub Cadet 607-04013

Bracket Assembly, Prop Rod

$

$

Not available

2

Cub Cadet 647-0068

Rod Assembly, Prop

$

$

Not available

3

Cub Cadet 707-0384

Tab, Bed Lift

$

$

Not available

4

Cub Cadet 707-04060

Bracket, Bed Latch Base

$

$

Not available

5

Cub Cadet 710-04029

Screw, Countersunk Socket, 5/16-18 x 1

$

$

Not available

6

Cub Cadet 710-0599

Screw, Self-tapping, 1/4-20, 0.50

$4.49

$

In Stock, Qty 20+

0

7

Cub Cadet 710-0899A

Screw, Hex Sems, #10-32 x .62, Gr5

$6.99

$

Usually ships in 3-6 days

0

8

Cub Cadet 710-3025

Hex Screw, 5/16-18 x .625, Gr5

$3.99

$

In Stock, Qty 8

0

9

Cub Cadet 712-0349

Hex Nut, 10-32

$4.99

$

In Stock, Qty 5

0

10

Cub Cadet 714-04001

Pin, Cotter, 0.125 OD
(Superseded to 914-0470)

$4.49

$

In Stock, Qty 20+

0

11

Cub Cadet 726-04005

Latch Assembly, Bed

$

$

Not available

12

Cub Cadet 731-2540

Handle

$

$

Not available

13

Cub Cadet 732-04007

Spring, .497 OD x 1.935

$

$

Not available

?14

Cub Cadet 736-04007

Washer, Flat, .51 ID x 1.05
(Superseded to 936-0272)

$4.99

$

In Stock, Qty 20+

0

15

UNKNOWN

$

$

Not available
