BFP60 A XRTA (BBFJ) - Honda Marine Engine, Made in Japan (SN: BBFJ-8000001 - BBFJ-9999999) CYLINDER HEAD Parts Diagram

Marine Engine, Made in Japan

CYLINDER HEAD Parts Diagram

  • Title
1

Honda 12155-ZV4-A00

SEE PART DETAILS - PRI; METAL, ANODE

$14.99

$

In Stock, only 1 left!

0

2

Honda 12210-ZZ3-000ZA

CYLINDER HEAD *NH8* (DARK GRAY)
(Superseded to 12210-ZZ3-020ZA)

$1279.99

$

Usually ships in 3-6 days

0

3

Honda 12217-ZW1-010

BOLT, SEALING (20MM)

$4.49

$

Usually ships in 3-6 days

0

4

Honda 12241-ZZ3-000

COVER, CAM THRUST

$28.99

$

Usually ships in 3-6 days

0

5

Honda 12251-ZZ3-003

GASKET, CYLINDER HEAD

$91.99

$

Usually ships in 3-6 days

0

6

Honda 12310-ZZ3-000

COVER, CYLINDER HEAD

$210.99

$

Usually ships in 3-6 days

0

7

Honda 12312-ZZ3-000

GASKET, HEAD COVER

$24.99

$

Usually ships in 3-6 days

0

8

$59.99

$

Usually ships in 3-6 days

0

9

Honda 15611-921-000

SEE PART DETAILS - PRI; CAP, OIL (YELLOW)

$13.99

$

Usually ships in 3-6 days

0

10

Honda 16700-ZZ3-003

PUMP ASSY., FUEL (MSDS)

$

$

Not available

11

Honda 16717-ZZ3-000

LIFTER, FUEL PUMP

$13.99

$

Usually ships in 3-6 days

0

12

Honda 16900-ZZ5-003

FILTER ASSY., FUEL

$81.99

$

Usually ships in 3-6 days

0

$17.99

$

In Stock, only 1 left!

0

$4.99

$

Usually ships in 3-6 days

0

$11.99

$

Usually ships in 3-6 days

0

16

Honda 16915-ZZ3-000

SUSPENSION, STRAINER

$16.99

$

Usually ships in 3-6 days

0

$3.49

$

In Stock, only 4 left!

0

$3.99

$

Usually ships in 3-6 days

0

19

Honda 19300-ZW9-003

THERMOSTAT ASSY.

$56.99

$

Usually ships in 3-6 days

0

20

Honda 19315-ZW9-000

COVER, THERMOSTAT

$14.99

$

In Stock, only 1 left!

0

21

Honda 19317-ZW9-000

O-RING, THERMOSTAT COVER

$6.99

$

In Stock, only 1 left!

0

22

Honda 19361-ZZ3-000

COVER, WATER JACKET

$57.99

$

Usually ships in 3-6 days

0

23

Honda 19371-ZZ3-000

GASKET, EX. WATER JACKET COVER
(Superseded to 19371-ZZ3-010)

$18.99

$

Usually ships in 3-6 days

0

24

Honda 31908-ZZ3-003

SPARK PLUG (LMAR6C-9)

$33.99

$

Usually ships in 3-6 days

0

25

Honda 35655-ZZ3-003

SENSOR, OXYGEN

$407.99

$

Usually ships in 3-6 days

0

26

Honda 35673-ZY3-003

SENSOR ASSY., WATER TEMPERATURE

$30.99

$

In Stock, only 1 left!

0

27

Honda 35695-ZY9-003

SENSOR ASSY., TDC

$122.99

$

Usually ships in 3-6 days

0

28

Honda 90003-ZW9-000

BOLT, FLANGE (6X22)
(Superseded to 90003-ZY9-M01)

$2.99

$

Usually ships in 3-6 days

0

29

Honda 90003-ZZ3-000

BOLT, FLANGE (8X90)
(Superseded to 90003-ZZ3-020)

$5.49

$

Usually ships in 3-6 days

0

30

Honda 90004-ZZ3-000

BOLT, STUD (8X32)

$3.49

$

Usually ships in 3-6 days

0

31

Honda 90007-MEL-003

BOLT-WASHER (9X105)

$6.49

$

Usually ships in 3-6 days

0

32

Honda 90011-ZZ3-000

BOLT, HEAD COVER
(Superseded to 90011-ZZ3-020)

$3.49

$

Usually ships in 3-6 days

0

33

Honda 90017-ZY3-000

BOLT, FLANGE (6X16)
(Superseded to 90017-ZZ5-M01)

$1.99

$

In Stock, Qty 5

0

34

Honda 90018-ZW5-000

BOLT, FLANGE (6X20)

$2.49

$

Usually ships in 3-6 days

0

35

Honda 90030-ZY3-000

BOLT, FLANGE (6X22)

$1.49

$

Usually ships in 3-6 days

0

36

Honda 90063-ZY3-000

BOLT, FLANGE (6X37)
(Superseded to 90063-ZVL-010)

$2.49

$

Usually ships in 3-6 days

0

37

Honda 90082-ZW4-H01

CAP, BOLT (6MM)

$4.99

$

Usually ships in 3-6 days

0

38

Honda 90158-ZW4-000

BOLT, FLANGE (8X70)
(Superseded to 90158-ZW4-030)

$2.99

$

Usually ships in 3-6 days

0

39

Honda 90606-ZW5-030

CLAMP, TUBE (D29)

$4.49

$

Usually ships in 3-6 days

0

40

Honda 90683-SA0-003

CLIP, WIRE HARNESS (25MM)

$12.99

$

Usually ships in 3-6 days

0

41

Honda 91201-ZE3-004

OIL SEAL (35X52X8)

$10.99

$

In Stock, Qty 9

0

42

Honda 91301-805-000

O-RING (26X2.7)

$4.99

$

Usually ships in 3-6 days

0

43

Honda 91302-PX4-004

O-RING (46.8X2.2) (NOK)

$9.49

$

Usually ships in 3-6 days

0

44

Honda 91303-ZW9-000

O-RING (31.2X2.4)

$3.99

$

Usually ships in 3-6 days

0

45

Honda 91307-PNA-003

O-RING (9.5X1.9)

$2.99

$

Usually ships in 3-6 days

0

46

Honda 91333-PNA-003

O-RING (15X1.9)

$4.49

$

Usually ships in 3-6 days

0

47

Honda 93500-05020-4J

SCREW, PAN (5X20)

$1.49

$

Usually ships in 3-6 days

0

48

Honda 94109-20000

WASHER, DRAIN PLUG (20MM)

$1.99

$

In Stock, only 4 left!

0

49

Honda 19303-ZW9-003

RUBBER, RING

$7.49

$

Usually ships in 3-6 days

0
