BF8 AW XA (BZBC) - Honda Outboard Engine, Made in Japan (SN: BZBC-1300001 - BZBC-9999999) SHIFT SHAFT Parts Diagram

Outboard Engine, Made in Japan

SHIFT SHAFT Parts Diagram

  • Title

1

Honda 17710-881-840ZB

CONNECTOR, FUEL *NH282MU* (OYSTER SILVER METALLIC-U)

$

$

Not available

2

Honda 17711-881-000

CAP, FUEL JOINT

$

$

Not available

3

Honda 17951-921-030

KNOB, CHOKE

$15.99

$

Usually ships in 3-6 days

0

4

Honda 17953-921-010

GUIDE, CHOKE KNOB

$7.99

$

Usually ships in 3-6 days

0

5

Honda 24210-921-000

SPRING, CLICK

$

$

Not available

6

Honda 24610-881-010

SEE PART DETAILS - PRI; SHAFT, SHIFT

$51.99

$

Usually ships in 3-6 days

0

7

Honda 24612-881-030

ARM, GEARSHIFT

$

$

Not available

8

Honda 24621-921-010

BUSH, SHAFT

$7.49

$

In Stock, only 1 left!

0

9

Honda 32901-952-770

TIE, CABLE

$3.49

$

Usually ships in 3-6 days

0

10

Honda 35110-881-000

PLATE, SWITCH SHIELD

$32.99

$

Usually ships in 3-6 days

0

11

Honda 35120-881-000

PLATE, SWITCH SETTING

$32.99

$

Usually ships in 3-6 days

0

12

Honda 36180-881-A02

SEE PART DETAILS - SUP; SWITCH ASSY., EMERGENCY STOP

$

$

Not available

15

Honda 36182-ZV4-650

SEE PART DETAILS - SUP; WIRE, EMERGENCY
(Superseded to 36182-ZV4-651)

$25.99

$

Usually ships in 3-6 days

0

19

Honda 50281-881-841ZB

HANDLE, CARRYING *NH282MU* (OYSTER SILVER METALLIC-U)

$40.99

$

Usually ships in 3-6 days

0

20

Honda 63201-881-841ZB

LEVER, COVER LOCK *NH282MU* (OYSTER SILVER METALLIC-U)

$35.99

$

Usually ships in 3-6 days

0

21

Honda 63202-881-000

HOOK, COVER LOCK

$

$

Not available

22

Honda 63203-935-000

WASHER, COVER LOCK

$4.49

$

Usually ships in 3-6 days

0

23

Honda 63205-920-000

BUSH, COVER LOCK

$6.49

$

In Stock, only 1 left!

0

24

Honda 90016-920-000

BOLT, FLANGE (6X12)

$2.99

$

In Stock, only 3 left!

0

26

Honda 90302-921-000

NUT, HEX. (16MM)

$5.99

$

In Stock, only 1 left!

0

27

Honda 90455-881-000

SPRING, LEVER

$4.99

$

Usually ships in 3-6 days

0

28

Honda 90504-921-010

WASHER, PLAIN (6MM)

$1.99

$

In Stock, only 1 left!

0

30

Honda 90507-ZV4-000

WASHER, PLAIN (8MM)

$3.49

$

Usually ships in 3-6 days

0

31

Honda 90511-921-000

WASHER, PLAIN (10MM)

$1.49

$

Usually ships in 3-6 days

0

32

Honda 90512-921-010

WASHER (6MM)

$1.99

$

Usually ships in 3-6 days

0

33

Honda 90518-921-000

WASHER, PLAIN (8MM)

$1.99

$

In Stock, Qty 10

0

34

Honda 90754-921-010

PIN (5X17)

$12.99

$

Usually ships in 3-6 days

0

35

Honda 90756-921-000

PIN, COTTER (1.6MM)

$2.49

$

In Stock, Qty 5

0

36

Honda 92101-06012-0B

BOLT, HEX. (6X12)

$1.99

$

Usually ships in 3-6 days

0

37

Honda 92101-06016-0B

SEE PART DETAILS - PRI; BOLT, HEX. (6X16)

$1.99

$

Usually ships in 3-6 days

0

38

Honda 92101-06020-4J

SEE PART DETAILS - PRI; BOLT, HEX. (6X20)

$1.99

$

Usually ships in 3-6 days

0

39

Honda 92101-06028-4J

BOLT, HEX. (6X28)

$6.49

$

Usually ships in 3-6 days

0

40

Honda 92101-08028-4J

BOLT, HEX. (8X28)

$4.49

$

Usually ships in 3-6 days

0

41

Honda 90115-881-000

BOLT, HEX. (8X32)

$5.99

$

Usually ships in 3-6 days

0

42

Honda 92101-06008-0B

SEE PART DETAILS - PRI; BOLT, HEX. (6X8)

$2.49

$

Usually ships in 3-6 days

0

43

Honda 93500-05020-4J

SCREW, PAN (5X20)

$1.49

$

Usually ships in 3-6 days

0

45

Honda 31620-881-A02

RECTIFIER ASSY., REGULATOR

$214.99

$

Usually ships in 3-6 days

0

46

Honda 31650-881-A02

SEE PART DETAILS - PRI; RECEPTACLE ASSY., CHARGE

$

$

Not available

47

Honda 31651-881-A01

RECEPTACLE

$

$

Not available

48

Honda 31652-881-014

SEE PART DETAILS - SUP; PLUG, RECEPTACLE
(Superseded to 31652-881-024)

$23.99

$

Usually ships in 3-6 days

0

48

Honda 31652-881-024

SEE PART DETAILS - PRI; PLUG, RECEPTACLE

$23.99

$

Usually ships in 3-6 days

0

49

Honda 32653-HA8-680

GROMMET, FUSE HOLDER

$4.49

$

Usually ships in 3-6 days

0

50

Honda 35100-881-003

SWITCH ASSY., NEUTRAL

$

$

Not available

51

Honda 37210-ZV4-003

SEE PART DETAILS - PRI; LAMP ASSY., INDICATOR

$52.99

$

Usually ships in 3-6 days

0

52

Honda 90014-ZV1-000

SEE PART DETAILS - SUP; BOLT, FLANGE (5X22)
(Superseded to 90014-ZV1-010)

$1.99

$

Usually ships in 3-6 days

0

52

Honda 90014-ZV1-010

SEE PART DETAILS - PRI; BOLT, FLANGE (5X22)

$1.99

$

Usually ships in 3-6 days

0

53

Honda 94001-05490-0S

NUT, HEX. (5MM)

$1.49

$

Usually ships in 3-6 days

0

54

Honda 95701-06025-02

BOLT, FLANGE (6X25)

$1.99

$

Usually ships in 3-6 days

0

55

Honda 98200-10500

FUSE A (5A)

$1.49

$

In Stock, only 3 left!

0
