BF8 AK0 LA (BZBC) - Honda Outboard Engine, Made in Japan (SN: BZBC-2100001 - BZBC-9999999) CARBURETOR Parts Diagram

Outboard Engine, Made in Japan

CARBURETOR Parts Diagram

  • Title

1

Honda 16010-881-A00

GASKET SET

$16.99

$

Usually ships in 3-6 days

0

2

Honda 16011-881-741

SEE PART DETAILS - PRI; VALVE SET, FLOAT

$31.99

$

Usually ships in 3-6 days

0

3

Honda 16013-881-003

SEE PART DETAILS - PRI; FLOAT SET

$

$

Not available

4

Honda 16015-881-A00

CHAMBER SET, FLOAT

$

$

Not available

5

Honda 16016-ZV1-E01

SCREW SET (CARBURETOR NO.)

$13.99

$

Usually ships in 3-6 days

0

6

Honda 16024-ZY3-000

SEE PART DETAILS - PRI; SCREW SET, DRAIN (CARBURETOR NO.)

$16.99

$

Usually ships in 3-6 days

0

7

Honda 16028-ZV4-650

SEE PART DETAILS - PRI; SCREW SET

$12.99

$

Usually ships in 3-6 days

0

7

Honda 16028-881-A00

SEE PART DETAILS - SUP; SCREW SET B
(Superseded to 16028-ZV4-650)

$12.99

$

Usually ships in 3-6 days

0

8

Honda 16081-ZV1-A00

SCREW, PAN

$2.49

$

Usually ships in 3-6 days

0

9

Honda 16100-881-E22

SEE PART DETAILS - PRI; CARBURETOR ASSY. (BC01G B)

$

$

Not available

10

Honda 16166-881-C40

NOZZLE, MAIN

$

$

Not available

11

Honda 16201-881-850

SEE PART DETAILS - PRI; GASKET, CARBURETOR

$3.49

$

In Stock, only 2 left!

0

12

Honda 16593-881-010

ROD, THROTTLE

$

$

Not available

13

Honda 16622-881-000

ROD, CHOKE

$

$

Not available

14

Honda 17201-881-C40

SEE PART DETAILS - SUP; GUIDE, AIR

Note: Use up to Engine SN 1309198.

$

$

Not available

14

Honda 17201-881-C42

GUIDE, AIR

Note: Use from Engine SN 1309199.

$

$

Not available

15

Honda 17202-921-000

COLLAR, DISTANCE

$

$

Not available

16

Honda 17203-881-000

TRAP, FLAME

$

$

Not available

17

Honda 90012-882-010

BOLT, FLANGE (6X97)

$

$

Not available

18

Honda 95003-05008-60M

BULK HOSE, VINYL (3.5X6.5X8000) (9500(95003-05001-60M) (CARBURETOR NO.)

$28.99

$

In Stock, only 1 left!

0

19

Honda 99101-ZH8-0820

SEE PART DETAILS - PRI; JET, MAIN (#82) (Honda Code 5947130).

Note: (Optional)

$7.99

$

Usually ships in 3-6 days

0

19

Honda 99101-ZH8-0850

SEE PART DETAILS - PRI; JET, MAIN (#85) Use up to Engine SN BE81B B.

Note: (Optional)

$7.99

$

Usually ships in 3-6 days

0

19

Honda 99101-ZH8-0880

SEE PART DETAILS - PRI; JET, MAIN (#88) Use up to Engine SN BE81B B.

$7.99

$

In Stock, only 1 left!

0

20

Honda 99103-881-0400

JET (#40)

$15.99

$

Usually ships in 3-6 days

0
