BF20 F SA (BF20) - Honda Outboard Engine, Made in Japan (SN: BF20-1000001 - BF20-9999999) OIL PAN Parts Diagram

Outboard Engine, Made in Japan

OIL PAN Parts Diagram

  • Title

1

Honda 11300-ZV0-000

SEE PART DETAILS - SUP; PAN, OIL

$

$

Currently unavailable

2

Honda 11381-ZV0-850

SEE PART DETAILS - PRI; GASKET, CASE COVER

$

$

Not available

3

Honda 15331-ZV0-000

SEE PART DETAILS - SUP; SLINGER, OIL
(Superseded to 15331-ZV0-010)

Note: Use up to Engine SN 1009662.

$8.99

$

Usually ships in 3-6 days

0

3

Honda 15331-ZV0-010

SEE PART DETAILS - PRI; SLINGER, OIL

$8.99

$

Usually ships in 3-6 days

0

4

Honda 15332-ZV0-000

GUIDE, OIL

Note: Use from Engine SN 1009663.

$10.99

$

Usually ships in 3-6 days

0

5

Honda 15332-896-700

SHAFT, OIL SLINGER

$

$

Not available

6

Honda 15620-ZG0-010

SEE PART DETAILS - SUP; CAP, OIL FILLER
(Superseded to 15620-ZG0-003)

$

$

Not available

7

Honda 15625-ZG0-000

SEE PART DETAILS - SUP; GASKET, OIL FILLER CAP

$3.49

$

In Stock, only 2 left!

0

8

Honda 15661-ZV0-003

FINDER, OIL LEVEL

$12.99

$

Usually ships in 3-6 days

0

9

Honda 90005-896-000

BOLT, FLANGE (5X16)

$2.99

$

Usually ships in 3-6 days

0

10

Honda 90015-ZV0-000

BOLT, FLANGE (6X28)

$3.49

$

Usually ships in 3-6 days

0

11

Honda 91201-896-701

SEE PART DETAILS - PRI; OIL SEAL (20X34X6)

$12.99

$

Usually ships in 3-6 days

0

12

Honda 91203-ZV0-003

SEAL, WATER (17X36X5.5)

$

$

Not available

13

Honda 94101-06800

SEE PART DETAILS - PRI; WASHER, PLAIN (6MM)

$0.99

$

In Stock, Qty 20+

0

14

Honda 94103-05800

WASHER, PLAIN (5MM)

Note: Use up to Engine SN 1009662.

$1.49

$

Usually ships in 3-6 days

0

15

Honda 94301-08140

SEE PART DETAILS - PRI; PIN A, DOWEL (8X14)

$2.99

$

In Stock, Qty 8

0
