BF2 DK0 SCAB (BZBJ) - Honda Outboard Engine, Made in Japan (SN: BZBJ-2300001 - BZBJ-9999999) HANDLEBAR + THROTTLE CABLE Parts Diagram

Outboard Engine, Made in Japan

HANDLEBAR + THROTTLE CABLE Parts Diagram

  • Title

1

Honda 16576-ZV0-010

HOLDER, CABLE
(Superseded to 16576-ZVA-000)

$3.99

$

Usually ships in 3-6 days

0

2

Honda 17910-ZVA-003

SEE PART DETAILS - PRI; CABLE A, THROTTLE

$43.99

$

Usually ships in 3-6 days

0

3

Honda 17920-ZVA-000

SEE PART DETAILS - PRI; CABLE B, THROTTLE

Note: Use up to Frame SN 2304439.

$7.99

$

Usually ships in 3-6 days

0

3

Honda 17920-ZVA-000

SEE PART DETAILS - PRI; CABLE B, THROTTLE

Note: Use from Frame SN 2304440.

$7.99

$

Usually ships in 3-6 days

0

3

Honda 17920-ZVA-000

SEE PART DETAILS - PRI; CABLE B, THROTTLE

Note: Use up to Frame SN 2314196.

$7.99

$

Usually ships in 3-6 days

0

3

Honda 17920-ZW6-020

SEE PART DETAILS - SUP; CABLE, THROTTLE (B)
(Superseded to 17920-ZVA-000)

Note: Use up to Frame SN 2304439.

$7.99

$

Usually ships in 3-6 days

0

3

Honda 17920-ZW6-020

SEE PART DETAILS - SUP; CABLE, THROTTLE (B)
(Superseded to 17920-ZVA-000)

Note: Use from Frame SN 2304440.

$7.99

$

Usually ships in 3-6 days

0

3

Honda 17920-ZW6-020

SEE PART DETAILS - SUP; CABLE, THROTTLE (B)
(Superseded to 17920-ZVA-000)

Note: Use up to Frame SN 2314196.

$7.99

$

Usually ships in 3-6 days

0

4

Honda 17921-ZV1-020

SEE PART DETAILS - PRI; HOLDER, CABLE
(Superseded to 17921-ZVA-000)

$6.99

$

Usually ships in 3-6 days

0

5

Honda 17930-ZW6-700

ARM, THROTTLE

$27.99

$

Usually ships in 3-6 days

0

8

Honda 17932-ZW6-700

SPRING, THROTTLE ARM
(Superseded to 17932-ZVA-000)

$2.99

$

Usually ships in 3-6 days

0

10

Honda 53101-ZW6-C00ZA

SEE PART DETAILS - PRI; HANDLEBAR *NH246* (LOOSY GRAY)

$123.99

$

In Stock, only 1 left!

0

11

Honda 53104-ZW6-700

BOLT, FRICTION
(Superseded to 53104-ZVA-000)

$9.49

$

Usually ships in 3-6 days

0

12

Honda 53106-ZW6-700

BLOCK, THROTTLE FRICTION
(Superseded to 53106-ZVA-000)

$9.49

$

Usually ships in 3-6 days

0

13

Honda 53107-ZV0-000

COLLAR, HANDLE MOUNTING
(Superseded to 53107-ZVA-000)

$3.99

$

Usually ships in 3-6 days

0

14

Honda 53108-ZV0-000

RUBBER, HANDLE MOUNTING
(Superseded to 53108-ZVA-010)

$2.99

$

Usually ships in 3-6 days

0

15

Honda 53109-ZV0-000

COLLAR, DISTANCE

Note: Use up to Frame SN 2304810.

$8.99

$

Usually ships in 3-6 days

0

16

Honda 53140-GW0-000

GRIP, THROTTLE

$20.99

$

Usually ships in 3-6 days

0

17

Honda 53165-GW0-000

GRIP, R. HANDLE

$

$

Currently unavailable

19

Honda 53167-ZW6-701

SEE PART DETAILS - PRI; HOUSING, THROTTLE (LOWER)
(Superseded to 53167-ZVA-000)

$16.99

$

Usually ships in 3-6 days

0

20

Honda 53168-GAH-A00

HOUSING, THROTTLE (UPPER)

$13.99

$

Usually ships in 3-6 days

0

21

Honda 77235-GC2-000

COLLAR, SEAT CATCH

$2.49

$

Usually ships in 3-6 days

0

21

Honda 91553-ZVA-010

SEE PART DETAILS - PRI; COLLAR (6.2X8.5X5)

$2.49

$

Usually ships in 3-6 days

0

23

Honda 90056-ZY3-000

BOLT, FLANGE (6X12)
(Superseded to 90056-ZY9-M01)

$1.49

$

Usually ships in 3-6 days

0

24

Honda 90101-ZW6-700

BOLT, HEX. (6X24)

$6.49

$

Usually ships in 3-6 days

0

25

Honda 90105-ZV0-000

BOLT, FLANGE (8X40)

Note: Use up to Frame SN 2304810.

$

$

Not available

26

Honda 90302-ZW4-000

NUT, HEX. (6MM)

$1.49

$

Usually ships in 3-6 days

0

28

Honda 90508-ZV0-000

WASHER (12.5X32)

$5.49

$

Usually ships in 3-6 days

0

29

Honda 90511-ZV4-000

WASHER, PLAIN (6MM)

$2.99

$

In Stock, only 1 left!

0

30

Honda 92101-06014-4J

BOLT, HEX. (6X14)

$1.99

$

Usually ships in 3-6 days

0

31

Honda 93500-05020-4J

SCREW, PAN (5X20)

$1.49

$

Usually ships in 3-6 days

0

32

Honda 94001-05490-0S

NUT, HEX. (5MM)

$1.49

$

Usually ships in 3-6 days

0

33

Honda 94001-06490-0S

NUT, HEX. (6MM)

$2.99

$

In Stock, only 1 left!

0

34

Honda 90105-ZW6-000

BOLT, SPECIAL (8X42)
(Superseded to 90102-ZVA-000)

Note: Use from Frame SN 2304811.

$10.99

$

Usually ships in 3-6 days

0

35

Honda 90501-ZV0-000

WASHER, PLAIN (8MM)
(Superseded to 90501-ZVA-000)

Note: Use from Frame SN 2304811.

$4.49

$

Usually ships in 3-6 days

0
