BF2 DK0 LCHA (BZBF) - Honda Outboard Engine, Made in Japan (SN: BZBF-2300001 - BZBF-9999999) SWIVEL CASE Parts Diagram

Outboard Engine, Made in Japan

SWIVEL CASE Parts Diagram

  • Title

1

Honda 50201-ZW6-C00ZA

CASE, SWIVEL *NH246* (LOOSY GRAY)

Note: Use from Frame SN 2301001.

$67.99

$

Usually ships in 3-6 days

0

1

Honda 50201-ZW6-000ZA

CASE, SWIVEL *NH246* (LOOSY GRAY)

Note: Use up to Frame SN 2301000.

$

$

Not available

2

Honda 50203-ZW6-000ZA

CAP, SWIVEL CASE *NH246* (LOOSY GRAY)

Note: Use up to Frame SN 2301000.

$29.99

$

Usually ships in 3-6 days

0

2

Honda 50203-ZW6-010ZA

CAP, SWIVEL CASE *NH246* (LOOSY GRAY)

Note: Use from Frame SN 2301001.

$24.99

$

Usually ships in 3-6 days

0

3

Honda 50204-ZV0-000

COLLAR, SWIVEL CASE
(Superseded to 50204-ZVA-000)

$3.99

$

Usually ships in 3-6 days

0

4

Honda 50212-ZV0-010

BLOCK, FRICTION
(Superseded to 50212-ZVA-000)

$5.99

$

Usually ships in 3-6 days

0

5

Honda 50233-ZV0-000

SPRING, FRICTION ADJUSTING
(Superseded to 50233-ZVA-000)

$3.49

$

Usually ships in 3-6 days

0

6

Honda 50300-ZVA-000ZA

SEE PART DETAILS - PRI; BRACKET, STERN *NH246* (LOOSY GRAY)

$250.99

$

Usually ships in 3-6 days

0

6

Honda 50300-ZW6-020ZA

SEE PART DETAILS - SUP; BRACKET, STERN *NH246* (LOOSY GRAY)
(Superseded to 50300-ZVA-000ZA)

$250.99

$

Usually ships in 3-6 days

0

7

Honda 50302-ZVA-000

SEE PART DETAILS - PRI; RECEIVER, THRUST

$22.99

$

Usually ships in 3-6 days

0

7

Honda 50302-ZW6-000

SEE PART DETAILS - SUP; RECEIVER, THRUST
(Superseded to 50302-ZVA-000)

$22.99

$

Usually ships in 3-6 days

0

8

Honda 50303-ZV0-000

RUBBER, THRUST
(Superseded to 50303-ZVA-000)

$18.99

$

Usually ships in 3-6 days

0

9

Honda 50337-ZV0-000

COLLAR, DISTANCE

$16.99

$

Usually ships in 3-6 days

0

10

Honda 50511-ZV0-010

ARM, TILT LOCK
(Superseded to 50511-ZVA-000)

$14.99

$

Usually ships in 3-6 days

0

11

Honda 50516-ZVA-000

SEE PART DETAILS - PRI; SPRING, TILT LOCK

$2.49

$

Usually ships in 3-6 days

0

11

Honda 50516-ZV0-000

SEE PART DETAILS - SUP; SPRING, TILT LOCK
(Superseded to 50516-ZVA-000)

$2.49

$

Usually ships in 3-6 days

0

12

Honda 90106-ZV0-000

BOLT, SWIVEL CASE
(Superseded to 90106-ZVA-000)

$9.49

$

Usually ships in 3-6 days

0

13

Honda 90107-ZV0-000

BOLT, HEX. (8X110)

$6.99

$

Usually ships in 3-6 days

0

14

Honda 90108-ZV0-000

BOLT, DIAMOND (6X110)

$6.99

$

Usually ships in 3-6 days

0

15

Honda 90114-HW1-671

SEE PART DETAILS - PRI; BOLT, FLANGE (8X35)

Note: Use from Frame SN 2301001.

$5.49

$

Usually ships in 3-6 days

0

15

Honda 90116-881-000

BOLT, HEX. (8X40)

Note: Use up to Frame SN 2301000.

$5.99

$

Usually ships in 3-6 days

0

16

Honda 90301-ZVA-000

SEE PART DETAILS - PRI; WINGNUT

$8.49

$

Usually ships in 3-6 days

0

16

Honda 90301-ZV0-000

SEE PART DETAILS - SUP; WINGNUT
(Superseded to 90301-ZVA-000)

$8.49

$

Usually ships in 3-6 days

0

17

Honda 90501-ZV0-000

WASHER, PLAIN (8MM)
(Superseded to 90501-ZVA-000)

$4.49

$

Usually ships in 3-6 days

0

18

Honda 90507-ZV4-000

WASHER, PLAIN (8MM)

Note: Use up to Frame SN 2301000.

$2.99

$

Usually ships in 3-6 days

0

19

Honda 90512-ZV0-000

WASHER, PLAIN (6MM)

$4.49

$

Usually ships in 3-6 days

0

20

Honda 90518-921-000

WASHER, PLAIN (8MM)

$1.99

$

In Stock, Qty 10

0

21

Honda 90751-ZW6-000

PIN, SPRING (2.5X8)

$1.99

$

Usually ships in 3-6 days

0

22

Honda 90752-ZW6-000

PIN, SPRING (2.5X20)

$3.49

$

Usually ships in 3-6 days

0

23

Honda 90951-ZV7-010

NIPPLE, GREASE

$2.99

$

Usually ships in 3-6 days

0

24

Honda 94001-08490-0S

NUT, HEX. (8MM)

$3.49

$

Usually ships in 3-6 days

0
