BF130 A1 XA (BZBE) - Honda Marine Engine, Made in Japan (SN: BZBE-1200001 - BZBE-1299999) CYLINDER HEAD + CAMSHAFT Parts Diagram

Marine Engine, Made in Japan

CYLINDER HEAD + CAMSHAFT Parts Diagram

  • Title

1

Honda 12201-ZW5-010ZA

SEE PART DETAILS - SUP; CYLINDER HEAD SUB-ASSY. *NH8* (DARK GRAY)
(Superseded to 12201-ZW5-020ZA)

$920.99

$

Usually ships in 3-6 days

0

1

Honda 12201-ZW5-020ZA

SEE PART DETAILS - PRI; CYLINDER HEAD SUB-ASSY. *NH8* (DARK GRAY)

$920.99

$

Usually ships in 3-6 days

0

1

Honda 12201-ZW5-000ZA

SEE PART DETAILS - SUP; CYLINDER HEAD SUB-ASSY. *NH8* (DARK GRAY)
(Superseded to 12201-ZW5-020ZA)

Note: Use up to Engine SN 1013621.

$920.99

$

Usually ships in 3-6 days

0

2

Honda 12204-PJ7-305

GUIDE, VALVE (OVER SIZE)

$23.99

$

Usually ships in 3-6 days

0

3

Honda 12205-PJ7-305

GUIDE, EX. VALVE (OVER SIZE)

$27.99

$

Usually ships in 3-6 days

0

4

Honda 12210-PZ1-004

SEE PART DETAILS - PRI; SEAL A, VALVE STEM (NOK)

$5.99

$

In Stock, Qty 5

0

5

Honda 12211-PZ1-004

SEE PART DETAILS - PRI; SEAL B, VALVE STEM (NOK)

$5.99

$

In Stock, Qty 5

0

6

Honda 12513-P30-000

RUBBER, CYLINDER HEAD SEAL

$17.99

$

Usually ships in 3-6 days

0

7

Honda 14111-ZW5-000

CAMSHAFT

$641.99

$

Usually ships in 3-6 days

0

8

Honda 14431-ZW5-000

ARM A, IN. ROCKER

$52.99

$

Usually ships in 3-6 days

0

9

Honda 14432-ZW5-000

ARM B, IN. ROCKER

$52.99

$

Usually ships in 3-6 days

0

10

Honda 14436-ZW5-000

ARM, FUEL PUMP ROCKER

$43.99

$

Usually ships in 3-6 days

0

11

Honda 14441-ZW5-000

ARM A, EX. ROCKER

$52.99

$

Usually ships in 3-6 days

0

12

Honda 14442-ZW5-000

ARM B, EX. ROCKER

$52.99

$

Usually ships in 3-6 days

0

13

Honda 14461-ZW5-000

SHAFT, IN. ROCKER ARM

$65.99

$

Usually ships in 3-6 days

0

14

Honda 14471-ZW5-000

SHAFT, EX. ROCKER ARM

$

$

Not available

15

Honda 14635-ZW5-000

COLLAR, ROCKER (A)

$5.99

$

Usually ships in 3-6 days

0

16

Honda 14636-ZW5-000

COLLAR, ROCKER (B)

$4.49

$

Usually ships in 3-6 days

0

17

Honda 14647-PT0-000

WASHER, WAVE

$8.49

$

Usually ships in 3-6 days

0

18

Honda 14647-PY3-000

WASHER, IN. WAVE

$6.99

$

Usually ships in 3-6 days

0

19

Honda 14651-PAB-A00

COLLAR A, IN. ROCKER

$

$

Not available

20

Honda 14711-P0A-000

VALVE, IN. (TMSS)

$68.99

$

Usually ships in 3-6 days

0

21

Honda 14721-P0A-000

VALVE, EX. (TMSS)

$106.99

$

Usually ships in 3-6 days

0

22

Honda 14744-PT0-004

SCREW, TAPPET ADJUSTING

$11.99

$

Usually ships in 3-6 days

0

23

Honda 14761-PAB-A01

SPRING, IN. VALVE (ORANGE) (NHK SPRING)

$20.99

$

Usually ships in 3-6 days

0

24

Honda 14762-P0A-003

SEE PART DETAILS - SUP; SPRING, EX. VALVE (VIOLET) (NIPPON HATSUJO)

$

$

Not available

25

Honda 14765-PJ7-000

RETAINER, VALVE SPRING

$9.99

$

Usually ships in 3-6 days

0

26

Honda 14775-PM3-000

SEAT, VALVE SPRING

$8.99

$

Usually ships in 3-6 days

0

27

Honda 14781-PJ7-003

COTTER, VALVE (FUJI VALVE)

$7.99

$

Usually ships in 3-6 days

0

28

Honda 90017-ZW5-000

BOLT, FLANGE (8X76)

$5.49

$

Usually ships in 3-6 days

0

29

Honda 90206-PT0-004

NUT, TAPPET ADJUSTING

$4.99

$

Usually ships in 3-6 days

0

30

Honda 91213-PL2-003

OIL SEAL (35X50X8) (NOK)

$26.99

$

Usually ships in 3-6 days

0

31

Honda 94301-10160

PIN, DOWEL (10X16)

$3.49

$

In Stock, only 3 left!

0

32

Honda 95701-06040-02

BOLT, FLANGE (6X40)

$2.49

$

Usually ships in 3-6 days

0
