AGR 1300 H - Billy Goat Landscape Auger General Assembly 12 Parts Diagram

Landscape Auger

General Assembly 12 Parts Diagram

  • Title

10

Billy Goat 8165003

NUT-HEX-NYLK, FLG .375"-16 ZP

$0.99

$

Usually ships in 2-11 days

0

29

Billy Goat 8165001

NUT-HEX-NYLK, FLG .250"-20 ZP

$0.99

$

Usually ships in 2-11 days

0

61

Billy Goat 540215

BELT, DRIVE

$53.99

$

Usually ships in 2-11 days

0

87

Billy Goat 500334

ENGINE 13HP HONDA GX390UTQA2

$

$

Currently unavailable

88

Billy Goat 540222

BELT FINGER, .375 X 2.875, 90 DEG

$24.99

$

Usually ships in 2-11 days

0

90

Billy Goat 540298

PLATE, 1/2" WEIGHT

$

$

Currently unavailable

95

Billy Goat 8024064

BOLT CARRIAGE 3/8-16 X 2 1/2" ZP

$0.99

$

Usually ships in 2-11 days

0

96

Billy Goat 8024061

BOLT CARRIAGE 3/8"-16 X 1 3/4" ZP

$1.49

$

Usually ships in 2-11 days

0

97

Billy Goat 8024161

BOLT CARRIAGE 3/8-16 X 5" ZP

$1.49

$

Usually ships in 2-11 days

0

98

Billy Goat 8024022

BOLT CARRIAGE 1/4"-20 X 1" ZP

$0.99

$

Usually ships in 0 days

0

110

Billy Goat 540107

WA, IDLER

$66.99

$

Usually ships in 2-11 days

0

111

Billy Goat 362254

BUSHING .500" ID

$

$

Not available

112

Billy Goat 520061

PULLEY IDLER INSIDE 4"

$31.99

$

In Stock, only 1 left!

0

113

Billy Goat 382252

WSHR-STL,FLT .500"X.875"X.0747" MAB ZP

$0.99

$

Usually ships in 2-11 days

0

115

Billy Goat 382295

BLT-SLDR,SH.500"X2.00",.375"-16X.63"G8ZP

$9.99

$

Usually ships in 2-11 days

0

117

Billy Goat 540213

PULLEY, 4.00"

$175.99

$

Usually ships in 2-11 days

0

119

Billy Goat 500113

PULLEY IDLER 4" OD X 3/8"

$34.99

$

Usually ships in 2-11 days

0

120

Billy Goat 791081

BOLT EYE G-2 3/8" X 2"

$9.99

$

Usually ships in 2-11 days

0

121

Billy Goat 791079

NUT WASHER FACE

$0.99

$

Usually ships in 2-11 days

0

139

Billy Goat 5104676

SPRING-EXT, 1.5ODX4.750LGX.177WR, BLK

$

$

Currently unavailable

148

Billy Goat 8160003

NUT LOCK 3/8"-16 HEX

$0.99

$

In Stock, Qty 6

0
