997015 (Pro-Turn EV52 RD) - Gravely Pro-Turn 52" Zero-Turn Mower, Electric, Rear Discharge (SN: 000101 & Above) Discharge Chute - 52" - RD Parts Diagram

Pro-Turn 52" Zero-Turn Mower, Electric, Rear Discharge

Discharge Chute - 52" - RD Parts Diagram

  • Title

1

Gravely 09446900

CHUTE- 52" REAR DISCHARGE TIRE

$

$

Not available

2

Gravely 09449000

CHUTE- 52" REAER DISCHARGE

$

$

Not available

3

Gravely 09378653

HANDLE, CHUTE MOUNTING (RED)

$

$

Currently unavailable

4

Gravely 09438953

WLDMT- 52" DEFLECTOR BAFFLE

$

$

Not available

5

Gravely 09447051

PLATE- 52" TIRE CHUTE MTG

$

$

Not available

6

Gravely 06500821

NUT-LK-CTR-FLG .25-20 ZC120

$0.99

$

In Stock, Qty 20+

0

7

Gravely 06500840

NUT,LK-CTR-FLG .31-18 GF ZCC

$1.49

$

In Stock, Qty 20+

0

8

Gravely 06200310

BTL,RHSSN .313-18 X 1.25 G5 ZCC

$1.49

$

In Stock, Qty 5

0

9

Gravely 05901716

BLT, HEX .25-20X.75 G5 ZCC

$0.99

$

In Stock, Qty 20+

0

10

Gravely 09377751

PLATE, CHUTE MTG (BLACK)

$

$

Currently unavailable

11

Gravely 07500105

KNOB,WING .31-18 UNC NYL/TALC

$3.99

$

In Stock, Qty 20+

0

12

Gravely 06200307

BLT, RHSN .25-20X.750 G5 ZCC

$0.99

$

In Stock, Qty 20+

0

13

Gravely 06401001

WSHR,FLT .281X.625X.065 ZCC

$0.99

$

In Stock, Qty 20+

0
